EP2S60F672C4 FPGA

You can use the EP2S60F672C4 fpga to fix hard digital problems. This fpga has many parts and is made by Intel, which is also called Altera. It is important because it has lots of logic space and works well. Engineers pick this fpga for signal jobs, phone systems, and built-in systems. You also use it to connect L298N motor drivers for robots or automation projects.

Key Takeaways

The EP2S60F672C4 FPGA helps solve hard digital problems. It works well in telecommunications, robotics, and embedded systems.
This FPGA has a high logic density with more than 60,000 logic elements. You can make big and advanced digital designs with it.
You can program the EP2S60F672C4 using VHDL or Verilog. This lets you pick what works best for your project.
Always check the official datasheet for detailed information and rules. This helps make sure your project meets all the needs.
You can connect the EP2S60F672C4 FPGA to an L298N motor driver. This lets you control motors very well and improves robotics and automation projects.

FPGA Overview

What is EP2S60F672C4?

The EP2S60F672C4 is a strong fpga. It helps you fix hard digital problems. This device is part of the Stratix II family. The Stratix II family is fast and has lots of logic space. You use this fpga to make complex systems. These systems can be signal processors or smart controllers. The EP2S60F672C4 uses a 90 nm copper CMOS process. It works with a 1.2 V core voltage. This gives you quick speed and low power use. It also has special features. These features make your designs easier and better.

Tip: To learn what makes this fpga special, look at the table below. It lists the main features.

Feature	Description
Advanced Process	Made with a 90 nm copper CMOS process. It uses a 1.2 V core voltage. This gives high speed and low power use.
Adaptive Logic Module (ALM)	Uses ALMs to save resources. This helps build complex logic functions easily.
High Logic Density	Has about 60,440 logic elements. It is good for big and smart digital designs.
TriMatrix™ On-Chip Memory	Has three kinds of RAM blocks. You get around 2.4 Mbits of memory inside.
Dedicated DSP Blocks	Has 36 DSP blocks. These help with math tasks and make work faster.
High-Speed I/O	Supports many I/O standards. It can move data up to 1 Gbps.
Rich External Memory Interface	Works with many memory types. This makes board design simple and lets data move fast.
Flexible Clock Management	Has up to 12 PLLs for clock control. It supports clock speeds up to 500–550 MHz.
Bitstream Encryption and Reconfiguration	Uses AES encryption and remote updates. This keeps your device safe and easy to change.

Manufacturer

Intel, also called Altera, makes the EP2S60F672C4 fpga. You can trust Intel. They have made digital devices for a long time. Intel builds the Stratix II family for big electronics projects. You get help and updates from Intel. This keeps your systems working well.

Purpose

You use the EP2S60F672C4 fpga to build systems that need fast data work. This device is used in places that need strong computing. Examples are telecommunications, cars, and artificial intelligence. As technology grows, more people want advanced fpga solutions. The EP2S60F672C4 gives you speed, flexibility, and safety. You use it for jobs that need quick math, steady data transfer, and safe updates.

Features

Logic Array Blocks

Logic Array Blocks are the main part of the fpga. These blocks let you make complex digital circuits. The EP2S60F672C4 fpga has 3022 Logic Array Blocks. Each block is placed in a grid shape. This grid makes the design strong and flexible. You can use these blocks for many logic functions. The fpga also has embedded RAM and DSP columns. These extra parts help with math and storing data. The table below shows how this fpga compares to others:

FPGA Model	Number of LABs/CLBs
EP2S60F672C4	3022

You get lots of blocks to use. This lets you build bigger and smarter systems. The Logic Array Blocks help you work faster and easier.

Supply Voltage

It is important to know about supply voltage for this fpga. The EP2S60F672C4 uses a 1.2 V core voltage. This low voltage helps save power. You can make systems that use less energy. The design works well at this voltage. You get stable features for your projects. Many new fpgas use even lower voltages, but 1.2 V is still good for most jobs. The supply voltage keeps your system safe and steady.

Note: Lower voltage means less heat and better power use. Your designs will last longer and work better.

Performance

You want your digital systems to work fast. The EP2S60F672C4 fpga gives strong performance with its smart design. You get high logic density and flexible features. The built-in memory and DSP blocks help you process data quickly. The fpga has strong I/O resources. You can move data fast and connect to many devices. The design lets you control clocks with up to 12 PLLs. This helps with timing and speed.

You can see how this fpga compares to newer models in the table below:

Feature	EP2S60F672C4 FPGA	Other FPGAs (Newer Models)
Process Technology	90 nm	< 7 nm
Core Voltage	1.2 V	1.0 V or lower
Logic Density	High	Higher in newer models
Embedded Memory	Flexible architecture	More advanced memory options
I/O Resources	Robust	Enhanced I/O capabilities
Speed	Moderate due to lack of high-speed transceivers	Higher with modern transceivers
Power Consumption	Higher compared to newer generations	Lower power consumption
Application Suitability	Signal processing, communication, prototyping	Broader applications with advanced features

The EP2S60F672C4 fpga has strong features for signal processing and communication. The design gives good performance, but newer fpgas may use less power and run faster. You still get reliable features for many uses. The power use is higher than newer models, but you can fix this with smart choices.

Tip: Use the EP2S60F672C4 fpga features to balance speed and power. You can build good systems with the right design.

You can trust this fpga for many projects. The design helps you scale and work efficiently. You get special features that help you solve hard digital problems.

Applications

You can use the EP2S60F672C4 fpga in many important ways. This device helps you fix tough problems in digital systems. It is used where speed and accuracy are needed. The fpga works for many types of jobs, so engineers and students like it.

Digital Signal Processing

This fpga is used a lot in digital signal processing. It can do fast math and change data quickly. You can use it for:

Digital Signal Processing (DSP) and Filtering
FIR and IIR filters
FFT processing
Complex arithmetic operations
Advanced audio, video, and radar signal applications

These jobs need strong hardware. The fpga lets you do these tasks in real time. You can make music, video, or radar systems with it. The device helps your projects run fast and stay correct.

Tip: The fpga has special DSP blocks. You can use them to make your projects work better.

Telecommunications

Telecommunications need fast and steady data movement. The EP2S60F672C4 fpga works well in these systems. You can see how it helps in the table below:

Feature	Description
High-speed I/O interfaces	Supports reliable, gigabit-level data transmission.
Dynamic phase alignment circuitry	Makes sure timing is right for fast data transfer.
Communication protocol implementation	Can handle many communication protocols for networks.
Physical layer functions	Works in routers, switches, and backplane systems.
Logic capacity and flexible PLLs	Handles tricky timing and protocol changes for fast interfaces.

You can use the fpga in routers, switches, and network cards. These jobs need good timing and quick data paths. The device helps your systems run without problems.

Embedded Systems

You can use the EP2S60F672C4 fpga in many embedded systems. The table below shows some main uses:

Application Area	Description
Digital Signal Processing (DSP)	Great for DSP jobs like FIR/IIR filters and FFT, using DSP blocks for speed.
High-Speed Communication	Moves data fast and manages tricky protocols, good for telecom.
Memory Controllers	Can make memory controllers that move lots of data quickly, good for big data jobs.
Custom Logic and Embedded Acceleration	Runs special hardware for certain tasks, so CPUs can do other things.
Prototyping and Educational Development	Used in kits for testing ideas and learning about digital design.

You can use the fpga to make custom logic for your projects. Many engineers use it for memory controllers and hardware helpers. You can also use it to learn and try new things. The fpga gives you what you need to make your projects faster and better.

Note: The many ways you can use the EP2S60F672C4 fpga make it a great pick for lots of projects.

Programming

Design Tools

You need special tools to program the EP2S60F672C4 fpga. Intel Quartus II is the main software you use. It helps you design, build, and program your logic circuits. You also need hardware like USB-Blaster or JTAG. These connect your computer to the fpga. They let you load your design onto the chip.

Tool	Purpose
Intel Quartus II	Design, compilation, and programming
USB-Blaster or JTAG	Configuration of the device

Quartus II gives you a safe place to work on your projects. You can make, test, and change your design easily. USB-Blaster or JTAG sends your program to the fpga. This makes the whole process simple and smooth.

Tip: Make sure your programming hardware matches your fpga before you start.

You can look at some good and bad points of Quartus II and similar tools in the table below:

Advantages	Limitations
High logic density for complex designs	Obsolete and harder to source
Good performance-to-cost ratio	Higher power consumption than newer FPGAs
Easy migration within the same family	No modern high-speed transceivers
Stable and mature development tools	More difficult timing closure at high utilization
Proven reliability in industrial use	Limited scalability for future protocols

Quartus II is helpful for programming, but it does not have all the newest features. Still, it works well for most fpga projects.

VHDL & Verilog

You use VHDL and Verilog to program the EP2S60F672C4 fpga. These are special languages for digital systems. VHDL stands for VHSIC Hardware Description Language. Verilog is another language that many people use. Both help you write how your fpga should work.

You pick VHDL or Verilog based on what your project needs. VHDL is better for big and tricky designs. Verilog is easier to learn and use. Quartus II lets you use both languages. You write your code, test it, and then build it for the fpga.

Note: You can use both VHDL and Verilog in one project. This gives you more ways to program.

You use these languages to make parts, connect signals, and set up your system. Quartus II checks your code for mistakes. It helps you fix problems before you program the fpga.

Step-by-Step Guide

You can follow easy steps to program the EP2S60F672C4 fpga. Here is a simple guide to help you:

Create and Compile Your Design
First, write your logic in VHDL or Verilog. Use Quartus II to build your project. Make a programming file for the fpga.
Set Up the Programming Hardware
Connect the fpga to your computer with USB-Blaster or JTAG. Check that Quartus II finds your device. This gets your fpga ready for programming.
Load the Programming File into the Device
Open the Quartus II Programmer tool. Pick your programming file. Send it to the fpga. The tool puts your design on the chip.
Verify the Configuration and Operation
Test your fpga to see if it works right. Use Quartus II to check the programming. Run your system and make sure everything works.

Alert: Always test your fpga after you program it. This helps you find and fix problems early.

You do these steps each time you change your design. Programming gets easier as you practice more. You learn how to use the tools and languages better.

You can use Quartus II and hardware tools for many fpga projects. VHDL and Verilog let you control your design. The step-by-step guide helps you finish programming with confidence.

Datasheet

Accessing the Datasheet

You can find the official datasheet for the EP2S60F672C4 fpga on the internet. The datasheet tells you all the important details for your project. You should look at the datasheet before you start building or programming. Here are some places where you can get the datasheet:

Allelco Electronics Blog

Tip: The datasheet explains what the fpga can and cannot do. Reading it first helps you avoid making mistakes.

Key Specs

You need to know the main details about the EP2S60F672C4 fpga. These details help you see if this device is right for your project. The datasheet lists things like logic elements, memory, and speed. You should check for these details:

Logic elements: 60,440
Logic Array Blocks: 3022
On-chip memory: 2.4 Mbits
DSP blocks: 36
Number of I/O pins: 492
Core voltage: 1.2 V
Package type: 672-BBGA
Supported standards: LVTTL, SSTL, LVDS

You can use these details to compare this fpga with others. The datasheet also tells you how each feature works. This helps you see what the device can do.

Note: Always make sure your project needs match the details in the datasheet.

Pinout & Electrical

You should check the pinout and electrical details before you connect the fpga to other parts. The datasheet shows you the pin map and voltage levels. Here is a table with some important electrical details:

Parameter	Value
Manufacturer	Altera/Intel
Series	Stratix® II
Number of I/O	492
Voltage – Supply	1.15 V ~ 1.25 V
Operating Temperature	0 °C ~ 85 °C (TJ)
Package / Case	672-BBGA

The I/O banks work with many standards like LVTTL, SSTL, and LVDS. Each bank is made for different jobs. Some banks are good for regular signals. Others are best for fast data or clock signals. You should always follow the datasheet to keep your design safe and working well.

Alert: Using the wrong voltage or pin map can break your fpga. Always check the datasheet before you connect anything.

CAD & Block Diagram

CAD Models

You can use CAD models to help you design your circuit board with the EP2S60F672C4 FPGA. These models show you the exact size and shape of the chip. You see where each pin goes and how the chip fits on your board. Most engineers use these models in software like Altium Designer, Eagle, or KiCAD.

Here are some things you get from a CAD model:

3D view of the FPGA package
Pin layout for easy connection
Footprint for PCB design
Placement guide for other parts

Tip: Download the official CAD model from Intel’s website or trusted component libraries. This helps you avoid mistakes when you build your board.

You can check the table below to see what you find in a typical CAD model file:

CAD Model Feature	Description
Package Type	672-BBGA (Ball Grid Array)
Pin Count	672
Dimensions	Exact size for PCB placement
Pin Mapping	Shows each signal and power pin
3D Model	Visualizes the chip on your board

Block Diagram

A block diagram helps you understand how the EP2S60F672C4 FPGA works inside. You see the main parts and how they connect. This makes it easier to plan your project.

Here is what you find in a simple block diagram for this FPGA:

Logic Array Blocks (LABs)
Embedded RAM blocks
DSP blocks for math
I/O banks for signals
PLLs for clock control

You can look at the diagram and see how data moves through the FPGA. Each block does a special job. LABs handle logic. RAM stores data. DSP blocks do math. I/O banks send and receive signals. PLLs control timing.

Note: Use the block diagram to plan your connections and make sure your design works well.

If you want to draw your own block diagram, start with boxes for each main part. Connect them with arrows to show how data flows. This helps you explain your design to others.

Alternatives

When you choose an FPGA, you have many options. The EP2S60F672C4 is a strong choice, but you may want to look at other FPGAs. You can find similar chips in the Stratix II family or from other brands. This helps you pick the best part for your project.

Stratix II Family

The Stratix II family has several FPGAs. Each one gives you different logic sizes, memory, and features. If you need more or less power than the EP2S60F672C4, you can pick another model from this family. Here are some popular options:

Model	Logic Elements	Memory (Mbits)	I/O Pins	Package Type
EP2S15F484C3	15,600	0.5	342	484-FBGA
EP2S30F484C3	32,470	1.2	342	484-FBGA
EP2S60F672C4	60,440	2.4	492	672-BBGA
EP2S90F1020C4	90,480	3.9	764	1020-FBGA
EP2S130F1508C5	132,540	5.3	1,092	1508-FBGA

Tip: You can move your design to a bigger or smaller Stratix II FPGA if your needs change.

You get the same tools and design flow with each Stratix II chip. This makes it easy to upgrade or downgrade your project.

Other Brands

You can also look at FPGAs from other brands. Xilinx, Lattice, and Microchip make strong FPGAs. Each brand has its own features and tools. You may find a better fit for your project with one of these.

Xilinx Spartan-3: Good for low-cost and simple designs.
Xilinx Virtex-4: Offers high speed and more logic.
Lattice ECP2: Uses less power and works well for small boards.
Microchip (Microsemi) ProASIC3: Gives you flash-based security and low power.

Brand	Family	Key Feature
Xilinx	Spartan-3	Low cost, easy to use
Xilinx	Virtex-4	High speed, more logic
Lattice	ECP2	Low power, small size
Microchip	ProASIC3	Flash-based, secure

Note: Always check the datasheet and support for each brand before you choose.

You can try different FPGAs to see which one works best for your project. Each brand gives you new features and design ideas.

Pros & Cons

Strengths

When you pick the EP2S60F672C4 FPGA, you get lots of good things. This device works well for many types of projects. It is flexible and strong. Here are some main strengths:

High Logic Density: You can make big digital systems. The FPGA has more than 60,000 logic elements.
Rich On-Chip Memory: You get 2.4 Mbits of memory. This lets you save and use data fast.
Dedicated DSP Blocks: You can do math and signal jobs easily.
Flexible I/O Options: You can connect to many devices. It supports different standards.
Reliable Clock Management: You can use up to 12 PLLs. This helps keep timing steady and quick.
Proven Design Tools: You use Intel Quartus II. It is easy and works well.
Strong Security Features: You keep your design safe. AES encryption and remote updates help protect it.

Tip: These strengths help you build systems that are quick, safe, and work well for many uses.

Here is a short summary:

Strength	Benefit for You
High logic elements	Good for complex designs
On-chip memory	Fast data storage and access
DSP blocks	Makes signal jobs easier
Flexible I/O	Simple device connections
Clock management	Keeps timing correct
Security features	Keeps your design safe

Limitations

You need to know what the EP2S60F672C4 FPGA cannot do. Every device has some weak points. Here are the main ones:

Older Process Technology: The 90 nm process uses more power than new chips.
No High-Speed Transceivers: You cannot use this FPGA for the fastest data links.
Higher Power Consumption: Your system might need better cooling.
Larger Package Size: The 672-BBGA package takes up more space.
Limited Future Support: Newer FPGAs get more updates and features.
Obsolete for Some Applications: Some new protocols may not work well.

Note: Make sure these limits do not hurt your project before you pick this FPGA.

You can look at both the good and bad sides. This helps you choose if the EP2S60F672C4 is right for you.

Packaging

Package Type

You need to know the package type before you start your project with the EP2S60F672C4 FPGA. The package type tells you how the chip looks and how you can place it on your circuit board. This FPGA uses a 672-BBGA package. BBGA stands for Ball Grid Array. In this package, you see small solder balls on the bottom of the chip. These balls connect the FPGA to your printed circuit board (PCB).

Key facts about the 672-BBGA package:

You get 672 connection points (balls) for signals and power.
The package shape is square and flat.
You need special tools to solder this chip to your board.
The BBGA package helps the FPGA stay cool and work well at high speeds.

Tip: Always check your PCB design software for the correct BBGA footprint. This helps you avoid mistakes when you place the chip.

Here is a quick table to help you remember the main features:

Feature	Value
Package Type	672-BBGA
Ball Pitch	1.0 mm
Dimensions	About 27 mm x 27 mm

Part Number

You can find the right FPGA by looking at the part number. The part number gives you important details about the chip. For this FPGA, the part number is EP2S60F672C4.

Let’s break down what each part means:

EP: Stands for "Erasable Programmable".
2S60: Shows the family (Stratix II) and logic size (60,440 elements).
F672: Tells you the package type (Fine-pitch 672-ball BGA).
C4: Shows the speed grade and temperature range.

Note: Always match the part number on your chip with your design files. This helps you avoid errors and get the right performance.

If you order parts, use the full part number. This makes sure you get the exact FPGA you need for your project.

Manufacturer Info

About Intel/Altera

Intel is a big name in computer chips. They make chips for computers and other gadgets. Altera was a company that made programmable chips. In 2015, Intel bought Altera. Now, Intel makes and sells all Altera products, like the Stratix II family. You get both Intel’s research and Altera’s experience. Intel brings new ideas and strong support. Altera gives lots of knowledge about programmable logic.

Intel designs fpga chips to help with tough digital problems. Their products are trusted because they test them a lot. Intel keeps making their chips better. Each new family has more features and works faster. Intel also works with many other companies. This means you can find tools and boards that fit your fpga.

Tip: Using an Intel chip means you are part of a big group of engineers and makers.

Support

You have many ways to get help with an Intel fpga. Intel has guides, datasheets, and videos on their website. You can follow step-by-step guides for your project. If you have a question, you can look in the Intel forums. Many engineers share tips and answers there.

Intel gives software updates for tools like Quartus II. You can download the newest version for more features. If you need extra help, you can contact Intel support. They answer questions about products, tools, and design problems.

Here are some ways you can get support:

Online guides and datasheets
Community forums and FAQs
Video lessons and webinars
Direct help from technical support

Support Type	Where to Find It
Documentation	Intel website
Community Forums	Intel FPGA forums
Software Updates	Quartus II download page
Technical Support	Intel support portal

Note: Always check the Intel website for the latest guides and updates.

Connect L298N

Interfacing with FPGA

You can connect l298n motor driver to your EP2S60F672C4 FPGA to control motors in your project. The L298N lets you drive DC motors and stepper motors. You send control signals from the FPGA to the L298N input pins. The FPGA gives you precise timing and logic for motor direction and speed.

To connect l298n, you first set up the FPGA output pins. You choose which pins will send signals to the L298N. You wire the FPGA pins to the IN1, IN2, IN3, and IN4 pins on the L298N. You also connect the enable pins to control motor power. The FPGA can use PWM signals to change motor speed.

Tip: Always check the voltage levels before you connect l298n. The L298N works with 5V logic, so you may need level shifters if your FPGA uses lower voltage.

Here is a simple example of how you connect l298n to your FPGA:

FPGA Pin 1 --> L298N IN1
FPGA Pin 2 --> L298N IN2
FPGA Pin 3 --> L298N IN3
FPGA Pin 4 --> L298N IN4
FPGA PWM Pin --> L298N ENA/ENB

Use Cases

You use the EP2S60F672C4 FPGA and connect l298n in many robotics and automation projects. You can build a robot car that moves forward, backward, or turns. You control the motors with your FPGA logic. You can also connect l298n for conveyor belts, robotic arms, or smart home devices.

Here are some common ways you use this setup:

Robot car movement and steering
Automated gates or doors
Conveyor belt speed control
Smart window openers
Simple CNC machines

You get fast response and flexible control when you connect l298n to your FPGA. You can change motor speed, direction, and timing with your code. This setup helps you learn about digital control and real-world hardware.

Note: When you connect l298n, you make your FPGA project more interactive and useful.

You now know the main features and uses of the EP2S60F672C4 fpga. This fpga helps you build fast and flexible digital systems. You can use it for signal processing, telecom, or embedded projects. Always check the datasheet for details before you start. Try new designs or explore other FPGAs to grow your skills. Your next project could be even better!

AiCHiPLiNK Logo

Written by Jack Elliott from AIChipLink.

AIChipLink, one of the fastest-growing global independent electronic components distributors in the world, offers millions of products from thousands of manufacturers, and many of our in-stock parts is available to ship same day.

We mainly source and distribute integrated circuit (IC) products of brands such as Broadcom, Microchip, Texas Instruments, Infineon, NXP, Analog Devices, Qualcomm, Intel, etc., which are widely used in communication & network, telecom, industrial control, new energy and automotive electronics.

Empowered by AI, Linked to the Future. Get started on AIChipLink.com and submit your RFQ online today!
