Operational Amplifiers Explained: Inverting vs Non-Inverting Op-Amps

Operational amplifiers: Compare inverting vs non-inverting op-amps, their phase, gain, and input impedance to select the best setup for your circuit.

Components & Parts

Inverting vs Non-Inverting Op-Amps

You may ask how operational amplifiers make signals stronger in different ways. An inverting amplifier turns the input signal upside down. A non-inverting amplifier keeps the signal the same way. With an operational amplifier, you can pick how the output will look. This depends on what you need. Knowing these setups helps you make better audio systems. It also helps with sensors or control circuits. If you want to use an op-amp, knowing the difference helps you choose the right one.

Key Takeaways

  • Learn how inverting and non-inverting amplifiers are different. Inverting amplifiers turn the signal upside down. Non-inverting amplifiers keep the signal the same way.

  • Use inverting amplifiers when you need to mix signals. They are good for changing the phase in audio work and control systems.

  • Pick non-inverting amplifiers if you want high input impedance. They help keep the signal's direction. These are best for sensors and audio devices.

  • Remember the gain formulas for each amplifier. Inverting amplifier gain is Av = -Rf/Rin. Non-inverting amplifier gain is Av = 1 + (Rf/Rin). Change the resistor values to get the gain you want.

  • Think about what your project needs before you choose an amplifier. Make sure the amplifier matches your signal strength and phase needs. Pick the right one for your job.

Op-Amp Configurations

Inverting Amplifier

There are two main ways to set up operational amplifiers. The inverting amplifier is very common. You connect the input signal to the inverting terminal, which has a minus sign (-). The non-inverting terminal, with a plus sign (+), connects to ground. The input does not touch the non-inverting side. This setup makes the signal stronger. The output flips upside down compared to the input. If you put in a positive voltage, the output turns negative. This flip is called phase inversion.

Here’s a simple table about phase:

Amplifier TypePhase Relationship with Input
Inverting Amplifier180 degrees out of phase
Non-Inverting AmplifierSame phase as input

You use an inverting setup when you want the output to go the opposite way from the input. This helps in audio mixers or signal processing circuits. The op-amp lets you control how much the signal changes.

Non-Inverting Amplifier

The non-inverting amplifier works in another way. You connect the input signal to the non-inverting terminal (+). The inverting terminal (-) connects to a feedback loop. It does not connect straight to the input. This setup keeps the output going the same way as the input. If you put in a positive voltage, the output stays positive. There is no phase flip here.

  • Inverting amplifiers make the output go the opposite way from the input.

  • Non-inverting amplifiers keep the output going the same way as the input.

Non-inverting amplifiers are used when you want to make a signal stronger but keep its direction. This is good for sensor circuits or audio amplifiers. Operational amplifiers in this setup help you get a strong, clean signal. The op-amp makes sure the output matches the input’s movement.

Operational Amplifier Basics

What is an Operational Amplifier?

You may wonder why operational amplifiers matter in electronics. An operational amplifier, or op-amp, is a small chip. It can make weak signals much stronger. You find op-amps in almost every electronic device. The main job of an operational amplifier is to boost voltage. These devices can do more than just amplify signals. They can add, subtract, and filter signals too.

Let’s look at how operational amplifiers started and what they did:

YearDevelopmentFunction
1941First vacuum tube op amp patented by Karl D. Swartzel Jr.Used for math in analog computers
WWIISwartzel's design used in M9 artillery directorHelped radar systems hit targets better

Operational amplifiers have been around for a long time. The first operational amplifier helped with math in old computers. Another operational amplifier helped radar systems work better in World War II.

When you learn about operational amplifiers, you see that the ideal operational amplifier has special features. The ideal operational amplifier gives perfect results, but real ones are close.

Common Features

There are some important features to know about operational amplifiers. The ideal operational amplifier has very high open loop gain. This means it can make a tiny signal much bigger without feedback. In real life, open loop gain is not endless, but it is still very high. The ideal operational amplifier also has infinite input impedance. This means it does not take current from your signal source. The output impedance of the ideal operational amplifier is zero, so it can drive any load easily.

Here is a table with the most important characteristics:

CharacteristicDescription
Open-loop gainGain without feedback, usually very high (10,000+), needed for stable circuits in closed-loop setups.
Input impedanceShould be infinite, so it does not load the source; changed by outside parts and feedback.
Output impedanceShould be zero, but is usually small; affects how much current it can give and how well it buffers voltage.
Frequency response and bandwidthHas a limited bandwidth with a -3dB point; higher bandwidth means better at high frequencies but may use more power or cost more.
Gain bandwidth product (GBP)Calculated as Gain times Bandwidth; helps you know how it works at different frequencies; higher GBP means better performance.

Open loop gain is important in operational amplifiers. The ideal operational amplifier has endless open loop gain, but real ones have limits. When you use operational amplifiers, you want high open loop gain for better results. You also want the ideal features as much as you can. If you remember these basics, you will find it easier to build good circuits.

Inverting Amplifier Details

Circuit Diagram

An inverting amplifier uses a simple setup. You connect your input signal to the inverting input. The non-inverting input connects to ground. A resistor goes between your signal source and the inverting input. Another resistor links the output back to the inverting input. This second resistor is called the feedback resistor. The output comes from the op-amp.

Here’s a basic diagram you might see in textbooks:

         +V
          |
         [ ]
          |
    Vin --Rin--+---(-) Op-Amp (+)--- Ground
               |      |
              Rf     Vout
               |      |
             Output  Ground

This setup is used when you want to flip the signal. The inverting op-amp turns your input signal upside down. If you send in a positive voltage, you get a negative output.

Gain Formula

You may wonder how to find the gain for an inverting amplifier. Gain shows how much the op-amp makes your signal bigger. In an inverting setup, the gain is negative. This means the output is stronger and flipped.

The voltage gain (Av) of an inverting amplifier is mathematically expressed as Av = -Rf/Rin, where Rf is the feedback resistor and Rin is the input resistor.

You use this formula to figure out the gain. To get more gain, make the feedback resistor larger. To get less gain, use a bigger input resistor. The negative sign means the signal is flipped.

Input Impedance

Input impedance is important when building circuits. It tells you how much the amplifier blocks current from your signal source. In an inverting op-amp, input impedance depends on the input resistor.

  • The input impedance of amplifiers can be from tens of ohms to millions of ohms, depending on the transistor type.

  • Bipolar transistor circuits usually have input impedances from tens of ohms to a few thousand ohms (kΩ).

  • FET-based transistor circuits can have input impedances up to millions of ohms (MΩ).

You choose the right input impedance for your project. If you use a summing amplifier, you match the impedance to your sources. Operational amplifiers help you do this easily.

Phase Shift

The inverting amplifier does more than make signals bigger. It also flips the phase. This phase shift is important for many uses.

  • The output signal of an inverting amplifier is shifted by 180 degrees compared to the input signal.

  • This phase shift is needed for jobs like audio processing.

  • Inverting amplifiers are used in analog signal processing, where you need exact amplification and phase changes.

You use inverting op-amps when you need to flip signals. If you work with audio mixers or summing amplifiers, phase shift helps you mix signals the right way. Negative feedback in these circuits keeps the output steady and correct.

Operational amplifiers make it easy to get the gain and signal flip you want. You can use inverting op-amps for many things, from simple amplifiers to complex signal processing. The feedback loop and negative feedback keep your output clean. You get control over gain, phase, and input impedance. That’s why inverting amplifiers are popular in electronics.

Non-Inverting Amplifier Details

Circuit Diagram

A non-inverting amplifier connects the input signal to the non-inverting input. The inverting input connects to two resistors that form a voltage divider. The output goes back to the inverting input through one resistor. This makes a feedback loop that sets the gain.

Here’s a simple diagram you might see:

         +V
          |
         [ ]
          |
    Vin --+---(+) Op-Amp (-)---+--- Ground
                |        |
              Vout      R1
                |        |
              Output    R2
                         |
                      Ground

This circuit keeps the output going the same way as the input. The non-inverting op-amp does not turn the signal upside down.

Gain Formula

You can change how much the non-inverting amplifier increases your signal. The formula for voltage gain is:

Av = 1 + (Rf / Rin)

Av means voltage gain. Rf is the feedback resistor. Rin is the resistor to ground. The gain is always positive, so the output matches the input’s direction. To get more gain, use a bigger feedback resistor. To get less gain, use a bigger resistor to ground.

Input Impedance

A big plus of the non-inverting amplifier is its high input impedance. When you connect your signal, the op-amp takes almost no current. This means your signal source does not get weaker. High input impedance is good for sensors or weak signals. You can use a non-inverting op-amp to keep a signal strong.

Phase Shift

The non-inverting amplifier keeps the output in phase with the input. There is no flip like with the inverting amplifier. This phase match is important for many uses:

  • Non-inverting amplifiers keep the input signal’s phase, so your signal stays clear.

  • You need this in audio work, where you want the sound to stay the same.

  • Non-inverting op-amps are good as buffers for sensors, so the signal direction does not change.

When you use a non-inverting amplifier, you get clean gain without flipping the signal. The feedback loop lets you set the gain where you want it. You can use this amplifier in many projects, like audio or sensor circuits. The non-inverting amplifier gives you strong and accurate signals.

Comparison and Applications

Key Differences

When you compare operational amplifiers, you notice some clear differences. The inverting amplifier and non-inverting amplifier work in different ways. You should know these differences before you choose one for your project. Here’s a table that shows the main features for each type:

FeatureInverting AmplifierNon-Inverting Amplifier
Input ConnectionSignal goes to (-) terminalSignal goes to (+) terminal
Output PhaseOutput is 180° out of phase (inverted)Output is in phase with input
GainNegative gain (-Rf/Rin)Positive gain (1 + Rf/Rin)
Input ResistanceLower input resistanceHigher input resistance
BandwidthLower bandwidth for same gainHigher bandwidth for same gain
NoiseHigher noise due to series resistanceLower noise due to lower resistance
DistortionLower input distortionHigher input distortion
StabilityMore stable with higher noise gainLess stable, needs gain of at least 2
CMRRZero common-mode inputLimited by common-mode signal

The inverting amplifier flips the signal and gives negative gain. The non-inverting amplifier keeps the signal direction and gives positive gain. Non-inverting amplifiers have higher input resistance. This helps when you use weak signals.

Tip: Use a non-inverting amplifier if you want the output to match the input phase. Pick an inverting amplifier if you need the output to be opposite.

Input/Output Characteristics

Think about how the input and output act in each amplifier. The operational amplifier changes these things based on how you set it up.

  • The inverting amplifier has lower input resistance. Your signal source must be strong enough to work with it. The output is always flipped, so you get a 180-degree phase shift. The gain depends on the feedback resistor and the input resistor. You can change the gain by changing these resistors.

  • The non-inverting amplifier gives you high input resistance. You can connect sensors or weak signals without losing strength. The output stays in phase with the input. The gain formula is always positive, so the signal does not flip. You set the gain with the feedback resistor and the resistor to ground.

Here’s a quick code block that shows the gain formulas for both types:

Inverting Amplifier Gain:     Av = -Rf / Rin
Non-Inverting Amplifier Gain: Av = 1 + (Rf / Rin)

Watch out for some common mistakes when you design these circuits:

  • Not checking the input common-mode voltage range can cause problems.

  • Using large feedback resistors can add noise and DC errors.

  • Not thinking about stability with fast operational amplifiers can lead to trouble.

Note: Always check your resistor values and input voltage range before you build your amplifier circuit.

Real-World Uses

Operational amplifiers are used in many devices. The inverting amplifier and non-inverting amplifier each have their own jobs. Let’s look at where you might use each one.

Inverting Amplifier Applications

Here’s a table that shows common uses for the inverting amplifier:

Application FieldDescription
Audio ProcessingUsed to make audio signals louder and clearer.
Industrial ControlHelps control systems work better and respond faster.
InstrumentationUsed to make signals bigger and flip them for measurements.
Communication SystemsUsed for many signal processing jobs.
Medical DevicesHelps devices process signals accurately.
Consumer ElectronicsFound in many devices to make signals stronger.

You use the inverting amplifier when you need to flip the signal or mix signals together. It works well in audio mixers, control systems, and measurement devices.

Non-Inverting Amplifier Applications

You see the non-inverting amplifier in places where you need to keep the signal direction and get high input resistance. Here are some common uses:

  • Sensor Interfacing: Buffering op amps help you connect sensors with high resistance to data systems. You get good readings.

  • Audio Equipment: These amplifiers drive speakers or headphones. The sound stays clear and strong.

  • Data Acquisition Systems: The amplifier makes input signals ready for digital conversion. You get accurate data.

  • Power Management Systems: The amplifier keeps voltage outputs steady. Your devices work well.

How to Choose the Right Amplifier

Think about a few things before you pick an operational amplifier setup:

  1. Decide if you want the output signal to match the input phase or be flipped.

  2. Check how strong and sensitive your signal source is.

  3. Figure out the gain you need for your project.

  4. Think about noise and bandwidth for your design.

If you want to mix signals or need phase inversion, use the inverting amplifier. If you need to buffer a weak signal or keep the phase, use the non-inverting amplifier. Operational amplifiers give you choices, so you can build circuits for audio, sensors, or control systems.

Remember: The right amplifier setup helps your project work better. Always match your amplifier choice to your signal needs and application.

You now know that operational amplifiers work in two main ways. The inverting amplifier turns your signal upside down. The non-inverting amplifier keeps the signal the same way. If you want high input impedance, use a non-inverting op-amp. Use this type if you need the phase to stay the same. If you need the signal to flip, pick the inverting setup. > Try making a simple operational amplifier circuit to see how they are different!












AiCHiPLiNK Logo

Written by Jack Elliott from AIChipLink.



AIChipLink, one of the fastest-growing global independent electronic   components distributors in the world, offers millions of products from thousands of manufacturers, and many of our in-stock parts is available to ship same day.



We mainly source and distribute integrated circuit (IC) products of brands such as BroadcomMicrochipTexas Instruments, InfineonNXPAnalog DevicesQualcommIntel, etc., which are widely used in communication & network, telecom, industrial control, new energy and automotive electronics.



Empowered by AI, Linked to the Future. Get started on AIChipLink.com and submit your RFQ online today!





Frequently Asked Questions

What happens if you swap the input terminals on an op-amp?

If you swap the input terminals, the amplifier changes its behavior. The output will flip phase. For example, an inverting amplifier becomes non-inverting, and vice versa. Always double-check your connections before powering up your circuit.

Can you use an op-amp as both inverting and non-inverting at the same time?

No, you cannot use both configurations at once in a single op-amp stage. You must pick one setup for each op-amp. If you need both, use two separate op-amps in your circuit.

Why does input impedance matter in amplifier circuits?

Input impedance tells you how much the amplifier loads your signal source. High input impedance means your source does not lose strength. This is important for sensors or weak signals. You want to keep your signal as strong as possible.

How do you choose resistor values for setting gain?

You pick resistor values based on the gain you want. For inverting amplifiers, use the formula Av = -Rf/Rin. For non-inverting, use Av = 1 + (Rf/Rin). Try different resistor values to see what works best for your project.

Are op-amps only for audio circuits?

No, you can use op-amps in many places. You find them in sensors, control systems, measurement tools, and even power supplies. Op-amps help you boost, filter, or mix signals in lots of electronic devices.
