REF02CSZ Explained: A Pro's Guide to this 5V Voltage Reference

Have you ever designed a circuit with a high-resolution ADC, only to find your measurements are noisy and inconsistent? You check your code, you check your layout, but the readings are still drifting all over the place. The problem might not be your ADC at all. It might be your voltage reference. In the world of precision electronics, the quality of your measurement is only as good as the "ruler" you're measuring against. That's where the REF02CSZ comes in.

This small 8-pin chip is a classic in analog design, and for a good reason. It's not a power supply; it's a precision instrument. A 2023 report on the data converter market highlighted that the push for higher-resolution data in IoT and medical devices is driving demand for high-stability references. While a common 7805 regulator gives you a functional 5V, the REF02CSZ gives you a trustworthy 5V.

This guide will explain everything you need to know about the REF02CSZ, from its pinout and core specs to why you would choose it over a common regulator, and how to use it to get rock-solid, reliable performance from your analog circuits.

1.0 What is the REF02CSZ? (And Why Isn't It Just a 7805?)

The REF02CSZ is a high-precision 5V voltage reference integrated circuit from Analog Devices. Its sole purpose is to output an extremely stable, accurate, and low-noise 5.0-volt signal, regardless of changes in temperature or input voltage.

This is the number one point of confusion for beginners. A voltage regulator (like an LM7805) and a voltage reference (like the REF02) are not the same thing.

• An LM7805 is a workhorse. It's designed to provide high current (1A or more) with "good enough" voltage accuracy. Its output can be noisy and will drift significantly with temperature. It's a power source.
• A REF02CSZ is a thoroughbred. It's designed to provide low current (10mA max) with exceptional voltage accuracy. Its output is clean, stable, and predictable. It's a measurement standard.

You use a 7805 to power your microcontroller. You use a REF02CSZ to tell your ADC exactly what 5.000V looks like.

1.1 A Precision 5V "Ruler" for Your Circuits

Think of an Analog-to-Digital Converter (ADC) like a person with a ruler trying to measure a stack of paper. * If you give the ADC a **7805 regulator** as its reference, you're giving it a "ruler" made of flimsy rubber. It might say "5V," but it stretches and shrinks with temperature and load, making all your measurements unreliable. * If you give the ADC a **REF02CSZ**, you're giving it a "ruler" made of solid, unbending titanium. It is *always* 5.0V, so your 12-bit or 16-bit measurements are always accurate.

1.2 Decoding the Part Number: REF02CSZ

Let's break down the part number: * **REF02:** This is the base part number for the 5V precision reference from Analog Devices. (The REF01 is the 10V version). * **C:** This is the **Grade**. "C" is the commercial grade, offering an initial accuracy of ±0.2% (±10mV) and a temperature coefficient (tempco) of 25 ppm/°C. * **S:** This is the **Package**. "S" indicates the 8-lead SOIC package. * **Z:** This indicates **RoHS compliance** (lead-free).

1.3 Key Datasheet Specifications

Here are the "at-a-glance" specs that matter to an engineer.

Parameter	Value	What it Means
Output Voltage	+5.0V	The precision reference output.
Initial Accuracy (C-Grade)	±0.2% (±10mV)	Out of the box, it's guaranteed to be between 4.990V and 5.010V.
Temp Coefficient ("Tempco")	25 ppm/°C (max)	This is its superpower. The output will only drift 0.000025V for every 1°C change.
Output Current	±10 mA	It can source or sink up to 10mA. It's not for power, just for reference.
Input Voltage Range	7V to 33V	It can take a wide, unregulated input and produce a perfect 5V output.
Line Regulation	0.005 %/V (max)	The output is nearly immune to changes in the input voltage.
Load Regulation	0.006 %/mA (max)	The output is nearly immune to changes in the load (up to 10mA).

2.0 REF02CSZ Pinout (SOIC-8 Package)

The REF02CSZ comes in a standard 8-pin SOIC package, making it easy to use on any modern PCB.

2.1 SOIC-8 (S-Suffix) Pin Configuration

2.2 Pin Functions Explained (V+, Vout, Trim...)

This is one of the most straightforward chips you'll ever use, but its extra pins add powerful features.

Pin No.	Name	Function
1	NC	No Connect. Leave this pin floating.
2	VIN	Input Voltage. Your unregulated power supply (7V to 33V).
3	TEMP	Temperature Output. A unique pin that outputs a voltage proportional to temperature.
4	GND	Ground. The system ground reference.
5	TRIM	Output Trim/Adjust. Allows you to fine-tune the 5V output.
6	VOUT	Precision 5V Output. This is the money pin.
7	NC	No Connect. Leave this pin floating.
8	NC	No Connect. Leave this pin floating.

3.0 REF02CSZ Applications: When to Use a Precision Reference

You should use a REF02CSZ in any circuit where your measurement needs to be more accurate than your power supply.

3.1 The #1 Use: Powering ADCs and DACs

This is the canonical application. High-resolution Analog-to-Digital Converters (ADCs) and Digital-to-Analog Converters (DACs) require a V_REF pin. * **For an ADC:** The ADC measures an unknown voltage by comparing it to V_REF. If V_REF is noisy or drifting, your entire measurement is junk. * **For a DAC:** The DAC creates an output voltage as a fraction of V_REF. If V_REF is unstable, the DAC's output will be just as unstable. Connecting the **REF02CSZ** output to the V_REF pin of a data converter is the standard design pattern for all high-precision systems.

3.2 High-Accuracy Measurement Systems

Any device that needs to provide a trustworthy reading falls into this category: * Digital multimeters * Laboratory power supplies * Data loggers * Medical instruments (like EKG machines or blood glucose meters)

3.3 Portable, Battery-Powered Instruments

The REF02 has excellent line regulation and a wide input voltage range (7V-33V). This means you can power it from a 9V battery, and even as the battery drains from 9V down to 7V, the 5.0V output will **not change**. This is something a simple Zener diode or 7805 just can't do.

4.0 How to Use the REF02CSZ: Basic Circuits & Features

This chip is wonderfully easy to implement.

4.1 Basic 5V Output Circuit

To get a standard 5.0V output, the circuit is simple: 1. Connect your unregulated input (e.g., +12V) to **Pin 2 (V_IN)**. 2. Connect **Pin 4 (GND)** to your system ground. 3. Connect the output **Pin 6 (V_OUT)** to your V_REF pin on your ADC/DAC. 4. Leave **Pin 3 (TEMP)** and **Pin 5 (TRIM)** unconnected. 5. **Add bypass capacitors!** Place a 1μF capacitor (tantalum or ceramic) from Pin 2 to Ground, and another 1μF capacitor from Pin 6 to Ground. This is **mandatory** for stability.

4.2 The "Temp" Pin: A Built-In Thermometer

A very cool feature of the REF02 is **Pin 3 (TEMP)**. This pin outputs a voltage that is directly proportional to the chip's temperature. * **Formula:** V_TEMP = (2.1 mV/K) × T(K) * **Use:** You can feed this voltage into one of your ADC channels to get a real-time temperature reading of your board. This is fantastic for adding temperature compensation to your measurements or for over-temperature protection.

4.3 Understanding the Trim Pin for Calibration

The **REF02CSZ** is already highly accurate, but **Pin 5 (TRIM)** allows for even finer, system-level calibration. By adding an external 10kΩ potentiometer, you can adjust the output voltage. * Connect the 10k potentiometer's wiper to Pin 5. * Connect one end of the pot to Pin 6 (V_OUT). * Connect the other end of the pot to Pin 4 (GND). This simple circuit gives you approximately ±150mV of adjustment range, allowing you to trim the output to an exact 5.0000V.

4.4 The Key Metric: Low Temperature Coefficient

The most important specification on a voltage reference datasheet is the **Temperature Coefficient** (or "Tempco"), measured in ppm/°C. This tells you how much the voltage will drift for every degree Celsius the temperature changes. * A **cheap Zener diode** might have a tempco of 500 ppm/°C. * The **REF02CSZ** has a *maximum* tempco of 25 ppm/°C.

This means it is 20 times more stable against temperature changes than a simple Zener. This stability is the entire reason the component exists.

---

In Conclusion

The REF02CSZ is a classic, high-performance component that solves a critical problem: it provides a stable, trustworthy 5V reference. While a simple regulator can power your circuit, it takes a precision reference like the REF02 to make your circuit's measurements accurate and repeatable. In any design where precision matters—from data acquisition to medical devices—investing in a high-quality reference is the first step to getting reliable data.

As the world of IoT and smart sensors continues to demand higher accuracy from smaller, battery-powered devices, the principles of precision voltage references embodied by the REF02CSZ are more important than ever.

If your design requires a rock-solid analog foundation, the REF02CSZ is a time-tested and reliable choice. Find this component and other high-performance data acquisition ICs on our site today.

Ready to get the precision your design deserves? Order your REF02CSZ components from AichipLink and ensure your measurements are always accurate.











Written by Jack Elliott from AIChipLink.
