How to Test CAN Bus Transceivers: Diagnosis and Troubleshooting Guide

To test CAN bus transceivers, first turn off the power for safety. Then, look at all the wires to check for damage or loose ends. Use a multimeter to check voltage and resistance at important spots. An oscilloscope lets you see if the signals look good. Always make sure the nodes can talk to each other. You should use a step-by-step way to find problems. This helps you find issues early and pick the right tools.

Key Takeaways

• Always turn off the power before you test CAN bus transceivers. This keeps you safe.

• Use a multimeter to check voltage and resistance at important spots. This helps you find problems fast.

• Look for signs of damage, like burnt connectors or melted wires. These can help you find what is wrong.

• Test if nodes can talk to each other to make sure your CAN bus network works right.

• Check your network often and look at it closely. This can stop big problems and keep it working well.

CAN Bus Transceiver Basics

What Is a CAN Bus Transceiver

A can bus transceiver is very important in a controller area network. You can find it in cars and in many machines at factories. This device connects digital signals from the CAN controller to the network wires. It changes data into special signals called differential signals. These signals move through the wires and help send messages, even with lots of electrical noise. The can bus transceiver also listens to the signals on the wires. It turns them back into data for the controller. This helps keep messages clear and fast. The can bus transceiver works well in tough places like cars and factories.

Tip: If you see problems with data or strange signals, check the can bus transceiver first.

Why CAN Bus Transceivers Matter

You need a strong can bus transceiver to keep your network working well. This device does more than just send and get signals. It helps protect the network from noise and mistakes. In cars and factories, many machines talk at the same time. The can bus transceiver makes sure each message gets through without errors.

• Precision: Messages arrive on time, so there are no delays and systems stay safe.

• Signal Integrity: The can bus transceiver keeps data clear, even with lots of noise.

• Data Accuracy: It checks for mistakes and stops wrong data from spreading.

• Synchronization: All network parts work together, so messages do not crash.

The can bus system has special features to keep working if something breaks. It uses differential signals to block noise. Error checks and ways to stop message crashes help the network stay strong. If you use a good can bus transceiver, your network will last longer and have fewer problems.

Symptoms of CAN Bus Transceiver Failure

Communication Errors

When a can bus transceiver starts to fail, you might see communication errors first. These errors can show up in different ways. Sometimes, messages do not get where they need to go. Other times, you might see weird data or missing parts. The can bus network needs clear signals to work well. If there are errors, you could see warning lights or error codes on your dashboard.

Here are some common symptoms you might notice:

• Data sometimes does not move between nodes

• The can bus network may stop working fully

• More error frames happen because messages get messed up

• Signals may not match and mess up the data flow

• The can bus transceiver might look damaged or feel hot

Diagnostic codes can help you find where the communication errors come from. You can use a scan tool to check for these codes. The table below lists some codes you might see:

Fault Code	Description
U0100	Lost Communication with ECM/PCM A
U0101	Lost Communication with TCM
U0121	Lost Communication with ABS Control Module
U0140	Lost Communication with Body Control Module
U0155	Lost Communication with Instrument Panel Cluster
U0401	Invalid Data Received from ECM/PCM
P0606	ECM/PCM Processor Issue

If you see these codes, check the can bus transceiver and the wires for problems. Many errors happen because of signal issues or voltage that does not match. You might also see more error frames on your scan tool. These errors mean the can bus network cannot send or get messages the right way.

Tip: If you see lots of communication errors or error codes, check the can bus transceiver and wires right away.

Physical and Electrical Signs

Physical and electrical signs can show if a can bus transceiver is failing. Look for things like burnt connectors or melted wire covers. If the transceiver gets too hot, it might stop working. You might even smell burnt plastic near the can bus network.

Checking electrical values helps you find problems fast. Use a multimeter to check voltage and resistance. The table below shows what numbers you should see:

Measurement Type	Expected Value
Voltage between CAN HI and GROUND	2.5 to 3.0 VDC
Voltage between CAN LOW and GROUND	2.0 to 2.5 VDC
Resistance between CAN HI and CAN LOW	28k – 50k ohms
Resistance between CAN HI and GROUND	Mega ohms or open
Resistance between CAN LOW and GROUND	Mega ohms or open
Resistance indicating damage	10K ohm or less
Low voltage indicating failure	1.4 VDC or less

If you see low voltage or resistance, there could be a problem with the can bus transceiver. These problems can stop messages or cause data loss. Always check your numbers against the expected values. If you find a problem, replace the transceiver or fix the wires to make the can bus network work again.

Note: Checking often helps you find problems early and keeps your can bus network working well.

Testing Tools for CAN Bus

When you test a CAN bus network, you need the right tools. These tools help you find problems quickly. They also make your checks more exact. You will use a multimeter, oscilloscope, CAN bus analyzer, and special software for testing.

Multimeter

A multimeter helps you check wires and voltage in your CAN bus network. You can use it to look at voltage and resistance fast. This tool helps you find wire problems or power issues before deeper tests.

Measurement Type	Expected Result
Voltage between CAN_L and Ground	1.5 to 2.5 volts DC
Resistance between CAN Hi and Low	About 60 ohms
Voltage between CAN HI and Ground	2.5 to 3.0 Vdc
Voltage between CAN LOW and Ground	2.0 to 2.5 Vdc
Resistance to Ground	Should be Mega ohms or open

To use a multimeter for testing:

1. Turn off the power.

2. Measure resistance between CAN Hi and CAN Low. You should see about 60 ohms.

3. Check voltages and ground wires.

4. Unplug all CAN devices except the one you want to test.

5. Turn on the device.

6. Measure voltage between CAN HI and Ground (2.5–3.0Vdc).

7. Measure voltage between CAN LOW and Ground (2.0–2.5Vdc).

8. Check ground wire to earth ground (less than 0.1 ohm).

Tip: Always match your readings to the table above for good results.

Oscilloscope

An oscilloscope lets you see CAN signals live. You use it to look closely at signals and find problems that a multimeter cannot show. This tool is important for advanced testing.

To set up your oscilloscope for CAN bus checks:

1. Connect probes to CAN_H and CAN_L lines. Use special probes for best results.

2. Add the CAN bus to a channel and check the source.

3. Set the voltage level, usually around 3V.

4. Pick the right CAN type (CAN 2.0, CAN FD, or CAN XL).

5. Enter the bit rate for the bus.

6. Set the sample point to about 75% of the bit time.

7. Turn on bus decoding and set bus details.

8. Read the decoded data on the screen for message checks.

Note: Oscilloscope checks help you see glitches, noise, or missing signals right away.

CAN Bus Analyzer

A CAN bus analyzer is your main tool for checking messages and tracking them. You use a CAN bus analyzer to capture, save, and test CAN frames. This tool helps you with both wire and message checks.

You can pick from many kinds of CAN bus analyzers:

• Simple handheld analyzers for quick checks

• Advanced analyzers for frame capture and saving

• CAN bus analyzers with software like JCOM.J1939 Gateway and JCOM1939 Software for message decoding and testing

A CAN bus analyzer lets you:

• Track message flow

• Save errors

• Test network traffic

• Run deep checks for problems

Tip: Use a CAN bus analyzer when you want to see how messages move through your CAN bus network.

Diagnostic Software

Diagnostic software makes CAN bus checks easier. You use it for watching, checking, and fixing problems. This software measures voltages, resistance, and bus load. It also tracks CAN traffic and finds errors quickly.

Diagnostic software can:

• Show you live CAN traffic

• Find and save errors

• Check both wires and messages

• Help you run quick checks with handheld tools

Note: Diagnostic software gives you a full look at your CAN bus network and helps you find problems before they get worse.

How to Test CAN Bus

Testing your CAN bus transceiver helps you keep your controller area network healthy. You need to follow a systematic process to make sure you find every problem. Each step checks a different part of the network. This way, you protect the integrity of your system and avoid missing hidden issues.

Visual Inspection

Start with a careful look at your wiring and connectors. You want to spot any damage before you use tools. Look for frayed wires, loose pins, or burnt spots. If you see melted insulation or corrosion, you may have found the cause of your problem.

• Check all connectors for tight fits.

• Look for broken or bent pins.

• Inspect cables for cuts or wear.

• Make sure there is no moisture or dirt on the board.

Tip: A quick visual check can save you hours of diagnostics later.

Power and Ground Checks

Power and ground connections are the backbone of your CAN bus network. If these connections fail, your system will not work. Always disconnect power before you begin. Use a multimeter to check for solid ground and correct voltage.

1. Turn off the power to your system.

2. Set your multimeter to measure resistance.

3. Place one probe on the ground pin and the other on a known good ground. You should see less than 0.1 ohm.

4. Switch your multimeter to voltage mode.

5. Turn the power back on.

6. Measure voltage at the CAN transceiver’s power pin. It should match your system’s rated voltage.

If you find high resistance or low voltage, fix these problems first. Good power and ground connections keep your network’s integrity strong.

Voltage and Resistance Testing

Now you need to test the electrical values in your CAN bus network. This step checks the integrity of your wiring and termination. Use a multimeter for these tests.

Parameter	Value
Normal Resistance	120Ω
Idle Voltage	2.5V
Differential Voltage	500mV

• Measure resistance between CAN_H and CAN_L with the power off. You should see about 120 ohms.

• Check idle voltage between CAN_H and ground. Expect about 2.5V.

• Measure the voltage difference between CAN_H and CAN_L during communication. It should be close to 500mV.

If your readings do not match the table, you may have a wiring or termination problem. These issues can affect the integrity of your signals and cause communication errors.

Signal Testing with Oscilloscope

An oscilloscope lets you see the real signals on your CAN bus. This tool helps you check the integrity of your waveforms. You want to make sure your signals are clean and strong.

• Analyze waveforms to verify signal integrity.

• Measure jitter, insertion loss, and crosstalk.

• Use both time and frequency domain analysis for a full picture.

• Start testing as soon as your device can send and receive signals.

• Use eye diagrams with mask tests to spot jitter and noise.

• Check waveforms at different points on your board to make sure they meet required values.

Note: A clean waveform means your CAN bus transceiver is working well. If you see noise or glitches, you may have a problem with integrity.

Communication Test Between Nodes

You need to make sure your nodes can talk to each other. This step checks the integrity of your data flow. Use diagnostic software or a CAN bus monitor for this test.

Diagnostic tools let you watch network traffic, send test messages, and check if data moves between nodes. This is key for reliable communication on your CAN bus. CAN bus monitors help you see messages, track devices, and spot error frames. These tools make troubleshooting easier.

To get the best results, pick hardware and software that match your system. Set up your test correctly. Make sure you connect to the CAN bus network and initialize your interfaces. Always verify that you have a good connection.

Testing with a known working node helps you check if your transceiver can send and receive messages. If your node cannot talk to a working node, you may have a transceiver or wiring problem. Testing with a known working node is a simple way to confirm the integrity of your network.

Tip: Always finish your test can bus process by checking communication between two nodes. This step proves your network’s integrity and helps you catch hidden problems.

Test and Diagnose Procedures

Identifying Faulty Transceivers

You need a systematic approach when diagnosing can bus transceivers. Faulty transceivers can cause many problems in your can bus network. You can use a step-by-step process to find the source of the issue. Follow these steps for accurate can bus diagnostics:

1. Disconnect the vehicle battery. This step ensures you get accurate resistance readings and keeps you safe during testing.

2. Find a can point by using the vehicle’s electrical diagram. This helps you know where to measure.

3. Measure the resistance between CAN-H and CAN-L. You should see about 60 ohms. If you see a different value, you may have a problem.

4. Check the internal resistance of the terminal resistance unit. It should read about 120 ohms.

5. Reconnect the unit and measure the resistance between CAN HIGH and CAN LOW again. The value should be 120 ohms.

6. Repeat this process for the other unit that has the terminating resistor.

7. Measure the resistance between each CAN line and ground. You should see several kilo-ohms. Low resistance here can mean a short circuit.

8. Take measurements from different points on the network. This helps you trace the current path and find where the problem starts.

Tip: Always use the same steps each time you test and diagnose. This habit helps you catch hidden issues and keeps your can bus network healthy.

If you find resistance values that do not match the expected numbers, you may have a faulty can bus transceiver. You should also check for shorts to ground or open circuits. These problems can stop communication and cause errors. Diagnosing can bus transceivers with these steps gives you a clear path to fixing your network.

Loopback and Message Tests

You can use loopback and message tests to confirm if your can bus transceiver works well. These tests help you check the sending and receiving functions without sending real messages on the bus. Loopback mode is a special feature in many can controllers.

Aspect	Description
Loopback Mode	Lets a CAN controller talk to itself for testing without sending messages on the bus.
Acknowledgment Limitation	A CAN node cannot acknowledge its own messages, so loopback is used for testing.
Message Reception Validation	The receiver checks messages through CAN frame bits, managed by the CAN controllers.

When you use loopback mode, you can send a message and see if the controller receives it. This test checks the basic function of the transceiver. You do not need to connect to the whole can bus network for this step. If the controller receives its own message, the transceiver likely works. If not, you may have a problem.

You can also run message tests between two nodes. Send a test message from one node and watch if the other node receives it. Use real-time monitoring tools or diagnostic software for this step. If both nodes send and receive messages, your can bus transceiver is working. If you see errors or missing messages, you need to keep diagnosing can bus transceivers.

Note: Real-time monitoring during these tests helps you spot problems as they happen. You can use can bus diagnostics tools for better results.

Testing, monitoring, and diagnosing can bus transceivers with these methods gives you confidence in your network. You can find faults early and keep your system running smoothly.

Troubleshooting a CAN Bus Network

Short and Open Circuits

When you work on a CAN bus network, you might find short or open circuits. These problems can stop the network from working right. If there is an open circuit, you may not see an ACK bit after sending a message. Some devices, like the TCAN1043, have an nFAULT pin that shows problems. But this pin does not always show if the bus is open. If you take out a CAN node, you might not get an ACK. This can also happen for other reasons. For short circuits, look for burnt smells or things that look damaged. Use a multimeter to check resistance between CAN lines and ground. If the resistance is low, there could be a short. If the resistance is high or you get no reading, it might be an open circuit.

• Look for missing ACK bits after you send messages.

• Check wires for damage you can see.

• Use a multimeter to check resistance between CAN_H, CAN_L, and ground.

• Watch for nFAULT signals if your device has them.

Tip: Split termination helps with noise but does not always help you find open circuits.

Termination Resistor Issues

Termination resistors are very important for a CAN network to work well. If you do not have them or put them in the wrong place, the network may act strange. Always turn off all devices before you test. Use a multimeter to check resistance between CAN-High and CAN-Low. You should see about 60 Ohms. Make sure there are two 120 Ohm resistors at each end of the bus. Do not put resistors inside devices unless the manual says you can. If you see a different number, check if a resistor is missing or if there are too many.

1. Turn off all devices.

2. Check resistance between CAN-High and CAN-Low.

3. Make sure you see about 60 Ohms.

Note: The right termination keeps your CAN network working well and helps with testing.

Noise and Interference

Noise can make your CAN network less reliable. There are ways to lower interference and make troubleshooting easier. The table below lists some ways to help:

Technique	Description
Proper Grounding	Gives current a good path and keeps signals clean.
Twisted Pair Cables	Lowers interference and keeps impedance close to 120 Ohms.
Isolated Transceivers	Helps block noise from other electronics in loud places.
Shielding	Stops EMI from motors and other machines.
Split Termination	Lowers reflections and keeps signals clear.

Tip: Use twisted pair cables and good grounding for the best results.

Replacing a Transceiver

If your CAN transceiver fails, you may need to put in a new one. First, turn on all power and stop all network messages. Use a multimeter to check the DC voltage between CAN_H and ground, and CAN_L and ground. You should see numbers between 2.0 V and 3.0 V. If the voltage is not in this range, the transceiver may be bad. Resistance should be more than 10 kΩ for each check. After you put in the new transceiver, test the network again to make sure it works.

• Turn on all power.

• Stop all network messages.

• Check DC voltage between CAN_H and ground, and CAN_L and ground.

• Change the transceiver if the numbers are not right.

Note: Careful steps help keep your CAN network working well and make troubleshooting easier.

Preventive Tips for CAN Bus Transceivers

Installation Best Practices

You can stop many problems by installing things the right way. Use twisted-pair cables because they help block noise. These cables keep your signals clear. Put each node in a straight line. This setup helps your can network avoid signal reflections. Always ground your system well. Good grounding keeps your can signals strong and safe from electrical noise. Think about how fast your data needs to move. Make sure your can network can handle the speed and bandwidth you need. After you finish installing, test everything. Troubleshooting right away helps you catch mistakes before they cause trouble.

• Use twisted-pair cables to lower noise.

• Put nodes in a straight line for better can communication.

• Ground your system well to keep signals safe.

• Make sure your can network can handle your data speed.

• Test and fix problems after you install everything.

Tip: Careful installation makes can maintenance easier and helps your network last longer.

Environmental Protection

Your can transceivers work best when you keep them safe from harsh places. Keep them away from water, dust, and heat. Use covers or boxes to protect your can devices. If you work in a factory or near engines, use transceivers made for tough places. These parts can handle vibration and big temperature changes. Clean your can connectors often. Dirt and rust can cause signal loss and make fixing things harder.

Protection Method	Benefit
Enclosures	Blocks dust and moisture
Heat shields	Stops overheating
Rugged transceivers	Handles shaking and shocks
Regular cleaning	Stops rust and dirt build-up

Note: Good protection means less fixing and fewer can failures.

Regular Maintenance

You need a good plan to keep your can network working well. Check your can wires and connectors often. Look for loose wires, bent pins, or signs of damage. Test your can voltages and resistance every time you check. Replace any broken parts right away. Keep a log for all your tests and repairs. This record helps you see patterns and plan future checks. Use tools to watch your can network. These tools warn you about problems early. Set up regular times for maintenance, not just when something breaks. Preventive maintenance saves you time and money.

• Check can wires and connectors every time you do maintenance.

• Test voltages and resistance as part of your routine.

• Replace broken parts quickly to stop bigger problems.

• Keep a log to track tests and repairs.

• Use tools to get early warnings about problems.

• Plan maintenance on a schedule, not just after things break.

Tip: Regular maintenance keeps your can network reliable and reduces downtime.

You can keep your CAN bus network working well by testing it safely and in steps. Using the right tools helps you find problems early. This stops small issues from becoming big failures. Hardware-in-the-Loop testing lets you check CAN communication in real situations. Being proactive means you fix bugs early and make your system stronger. Open-access test labs help lower risks for new CAN designs.

Evidence Type	Description
HIL Testing	Hardware-in-the-Loop simulation checks CAN communication in real conditions.
Proactive Approach	Early bug fixes boost reliability and performance.
Industry Insight	Open-access test labs lower risks for new CAN designs.

You can stop errors by looking for 120-ohm termination resistors. This keeps error rates low and makes your system more reliable.

Resistance Value	Error Rate	EMI Susceptibility	System Reliability
120 ohms	Low	Low	High
60 ohms	High	High	Low
No termination	Very High	Very High	Very Low

Keep checking and watching your CAN bus network often. If you still have trouble, you can ask an expert for help.











Written by Jack Elliott from AIChipLink.



AIChipLink, one of the fastest-growing global independent electronic   components distributors in the world, offers millions of products from thousands of manufacturers, and many of our in-stock parts is available to ship same day.



We mainly source and distribute integrated circuit (IC) products of brands such as Broadcom, Microchip, Texas Instruments, Infineon, NXP, Analog Devices, Qualcomm, Intel, etc., which are widely used in communication & network, telecom, industrial control, new energy and automotive electronics.



Empowered by AI, Linked to the Future. Get started on AIChipLink.com and submit your RFQ online today!
