APEX PA241DWA

Manufacturer No:

PA241DWA

Manufacturer:

APEX

Package:

10-SIP

Description:

120mA per Channel 100pA 94 dB Instrumentational OP Amps 0.002μA 100V~350V ±50V~175V PA241 10 Pins 10-SIP

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

PA241DWA information

APEX PA241DWA technical specifications, attributes, parameters and parts with similar specifications to APEX PA241DWA.

Type
Parameter

Mount
Through Hole

Mounting Type
Through Hole

Package / Case
10-SIP

Operating Temperature
-25°C~85°C

Packaging
Tube

Series
Apex Precision Power®

Published
2007

Pbfree Code
yes

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
10

ECCN Code
EAR99

Subcategory
Operational Amplifier

Technology
MOS

Terminal Position
SINGLE

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Number of Functions
1

Supply Voltage
150V

Terminal Pitch
2.54mm

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Base Part Number
PA241

Pin Count
10

Qualification Status
Not Qualified

Number of Circuits
1

Slew Rate
30V/μs

Architecture
VOLTAGE-FEEDBACK

Amplifier Type
Power

Common Mode Rejection Ratio
94 dB

Current - Input Bias
100pA

Voltage - Supply, Single/Dual (±)
100V~350V ±50V~175V

Output Current per Channel
120mA

Input Offset Voltage (Vos)
15mV

Gain Bandwidth Product
3MHz

Neg Supply Voltage-Nom (Vsup)
-150V

Unity Gain BW-Nom
3000 kHz

Average Bias Current-Max (IIB)
0.002μA

Low-Offset
NO

Frequency Compensation
NO

Low-Bias
YES

Micropower
NO

Programmable Power
NO

Power
YES

Voltage Gain-Min
32000

Length
25.4mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for APEX PA241DWA.

Datasheets:

apexmicrotechnology-pa241ce-datasheets-9492.pdf

PA241DWA Overview

A 10-SIP case is used to package the op amp. Power-type instrumentation amplifiers are used in this application. The case in which buffer amplifier is delivered is called a Tube case. It is estimated that there will be 10 terminations in the next few months. There are a total of 10 pins on this op amp. It is important to remember that this op amp should be operated at a voltage of 150V volts. It should be noted that this op amp is a type of Operational Amplifier device. In terms of the input offset voltage, instrumentation amplifier rates at 15mV. It is recommended that this electronic component be mounted using the Through Hole mounting type. In terms of operating temperature, this instrumentation amplifier performs well at a temperature of about -25°C~85°C . An 2.2mA volt supply current is needed for this linear amplifier to operate. On this instrumentation amplifier, there are 1 circuits that are connected together. The Apex Precision Power® indicates the series number of the op amp. There is a minimum voltage gain of 32000 that this buffer op amp is capable of conducting.
