Manufacturer No:

PI3PCIE2415ZHEX

Manufacturer:

DIODES

Package:

42-VFQFN Exposed Pad

Description:

42 Termination 0.5mm Analog Switch PCI Express®, TDP? Series PI3PCIE2415 3.3V 42-VFQFN Exposed Pad

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

PI3PCIE2415ZHEX information

DIODES PI3PCIE2415ZHEX technical specifications, attributes, parameters and parts with similar specifications to DIODES PI3PCIE2415ZHEX.

  • Type
  • Parameter
  • Factory Lead Time
  • 20 Weeks
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 42-VFQFN Exposed Pad
  • Operating Temperature
  • -40°C~85°C TA
  • Packaging
  • Tape & Reel (TR)
  • Series
  • PCI Express®, TDP?
  • Published
  • 2013
  • JESD-609 Code
  • e4
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 42
  • ECCN Code
  • EAR99
  • Resistance
  • 12Ohm
  • Terminal Finish
  • NICKEL PALLADIUM GOLD
  • Applications
  • PCI Express®
  • Terminal Position
  • QUAD
  • Terminal Form
  • NO LEAD
  • Peak Reflow Temperature (Cel)
  • 260
  • Number of Functions
  • 4
  • Supply Voltage
  • 3.3V
  • Terminal Pitch
  • 0.5mm
  • Time@Peak Reflow Temperature-Max (s)
  • 30
  • Base Part Number
  • PI3PCIE2415
  • Qualification Status
  • Not Qualified
  • Operating Supply Voltage
  • 1.8V
  • Supply Voltage-Max (Vsup)
  • 3.6V
  • Number of Channels
  • 4
  • Operating Supply Current
  • 2.5mA
  • RAM Size
  • 576B
  • Family
  • CB3Q/3VH/3C/2B
  • Logic Function
  • Demultiplexer, Multiplexer
  • Number of Inputs
  • 2
  • Output Characteristics
  • 3-STATE
  • Supply Type
  • Single
  • Output Polarity
  • TRUE
  • Logic IC Type
  • MULTIPLEXER AND DEMUX/DECODER
  • On-State Resistance (Max)
  • 12Ohm
  • Propagation Delay (tpd)
  • 12 ns
  • Multiplexer/Demultiplexer Circuit
  • 2:1
  • Number of Registers
  • 630
  • Voltage - Supply, Single (V+)
  • 3V~3.6V
  • Length
  • 9mm
  • Width
  • 3.5mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for DIODES PI3PCIE2415ZHEX.

PCN Packaging:

PI3PCIE2415ZHEX Overview
