Apex Microtechnology PA95

Manufacturer No:

PA95

Manufacturer:

Apex Microtechnology

Package:

12-SIP, 8 Leads

Description:

100mA per Channel 200pA 98 dB Instrumentational OP Amps 0.002μA 100V~900V ±50V~450V PA95 12-SIP, 8 Leads

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

PA95 information

Apex Microtechnology PA95 technical specifications, attributes, parameters and parts with similar specifications to Apex Microtechnology PA95.

Type
Parameter

Factory Lead Time
7 Weeks

Mount
Through Hole

Mounting Type
Through Hole

Package / Case
12-SIP, 8 Leads

Operating Temperature
-25°C~85°C

Packaging
Tube

Series
Apex Precision Power®

Published
2011

JESD-609 Code
e3

Pbfree Code
no

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
8

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - with Nickel (Ni) barrier

Subcategory
Operational Amplifier

Technology
HYBRID

Terminal Position
SINGLE

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Number of Functions
1

Supply Voltage
300V

Terminal Pitch
2.54mm

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Base Part Number
PA95

Qualification Status
Not Qualified

Power Supplies
+-50/+-450V

Number of Circuits
1

Operating Supply Current
1.6mA

Supply Current-Max
2.2mA

Slew Rate
30V/μs

Architecture
VOLTAGE-FEEDBACK

Amplifier Type
Power

Common Mode Rejection Ratio
98 dB

Current - Input Bias
200pA

Voltage - Supply, Single/Dual (±)
100V~900V ±50V~450V

Output Current per Channel
100mA

Input Offset Voltage (Vos)
500μV

Gain Bandwidth Product
10MHz

Neg Supply Voltage-Nom (Vsup)
-300V

Unity Gain BW-Nom
10000 kHz

Average Bias Current-Max (IIB)
0.002μA

Low-Offset
NO

Supply Voltage Limit-Max
450V

Low-Bias
NO

Bias Current-Max (IIB) @25C
0.002μA

Neg Supply Voltage-Max (Vsup)
-450V

Wideband
NO

Download datasheets and manufacturer documentation for Apex Microtechnology PA95.

Datasheets:

apexmicrotechnology-pa95-datasheets-2953.pdf

apexmicrotechnology-pa95-datasheets-3863.pdf

PA95 Overview

The linear amplifier is packaged in a 12-SIP, 8 Leads case which makes it easy for the consumer to handle. Op amps are Power types of amplifier on the chip. It comes in a Tube case, which protects instrumentation amplifier from damage during delivery. There have been a total of 8 terminations over the past year. Please take in mind that op amp should be run at 300V. It should be noted that this type of buffer amplifier is exactly what is known as a Operational Amplifier device. With regard to input offset voltage, instrumentation amplifier is rated at 500μV. This electronic part is best mounted with type Through Hole. Regarding the operating temperature of this device, instrumentation amplifier performs well at a temperature of -25°C~85°C . You can run this op amp ic on 1.6mA . On this buffer amplifier, there are 1 circuits. This buffer amplifier is assigned within the Apex Precision Power® series by its manufacturer.
