CIRRUS LOGIC PA243DF

Manufacturer No:

PA243DF

Manufacturer:

CIRRUS LOGIC

Package:

SOP

Description:

120mA per Channel 50pA 84 dB Instrumentational OP Amps 24 Pins SOP

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

PA243DF information

CIRRUS LOGIC PA243DF technical specifications, attributes, parameters and parts with similar specifications to CIRRUS LOGIC PA243DF.

Type
Parameter

Mount
Surface Mount

Package / Case
SOP

Number of Pins
24

JESD-609 Code
e3

Number of Terminations
24

ECCN Code
EAR99

Terminal Finish
MATTE TIN

Max Operating Temperature
85°C

Min Operating Temperature
-25°C

Subcategory
Operational Amplifier

Technology
MOS

Terminal Position
DUAL

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Number of Functions
2

Supply Voltage
150V

Terminal Pitch
1mm

Time@Peak Reflow Temperature-Max (s)
40

Pin Count
24

Qualification Status
Not Qualified

Max Output Current
120mA

Temperature Grade
AUTOMOTIVE

Number of Circuits
2

Max Supply Voltage
175V

Operating Supply Current
2.2mA

Slew Rate
30 V/μs

Architecture
VOLTAGE-FEEDBACK

Amplifier Type
OPERATIONAL AMPLIFIER

Common Mode Rejection Ratio
84 dB

Current - Input Bias
50pA

Output Current per Channel
120mA

Input Offset Voltage (Vos)
25mV

Bandwidth
30 kHz

Gain Bandwidth Product
3MHz

Neg Supply Voltage-Nom (Vsup)
-150V

Unity Gain BW-Nom
3000 kHz

Voltage Gain
96dB

Low-Offset
NO

Frequency Compensation
NO

Max Dual Supply Voltage
175V

Low-Bias
YES

Micropower
NO

Min Dual Supply Voltage
50V

Programmable Power
NO

Power
YES

Length
15.9mm

Height Seated (Max)
3.6mm

Download datasheets and manufacturer documentation for CIRRUS LOGIC PA243DF.

Datasheets:

cirruslogic-pa243df-datasheets-1316.pdf

PA243DF Overview

The linear amplifier is packaged in a SOP case. This is a OPERATIONAL AMPLIFIER type op amp. The number of terminations approaches 24. Buffer amplifier has a total of 24 pins. Please take in mind that this instrumentation amplifier should be run at 150V. To be specific, this instrumentation amplifier is a type of Operational Amplifier. The buffer op amp includes 24 pins. Regarding input offset voltage, op amp rates 25mV. This op amp can operate from a supply current at 2.2mA. Voltage gain should remain at 96dB. There are 2 circuits on this op amp. The temperature should not be lower than -25°C for operational amplifier ics to operate. Use op amps only at temperatures no higher than 85°C. With regard to the supply voltage, this electrical component is capable of working from under 175V. It is advised to keep the op amp's supply voltage higher than 50V. You should conduct this electronic component under the dual supply voltage of 175V.

PA243DF Features

24 Pins
supply voltage of 150V
96dB voltage gain

PA243DF Applications

There are a lot of Cirrus Logic
PA243DF Instrumentational OP Amps applications.

Inverse/same-phase proportional circuit
Addition operation circuits
Subtraction operation circuits
single/dual op amp sum and difference circuits
Integrator circuits
Differentiator circuits
Logarithmic operation circuits
Exponential operation circuits
Multiplication circuits
Division circuits
