NXP MK26FN2M0CAC18R
NXP MK26FN2M0CAC18R

NXP MK26FN2M0CAC18R

Manufacturer No:

MK26FN2M0CAC18R

Manufacturer:

NXP

Package:

169-UFBGA, WLCSP

Description:

2MB 2M x 8 FLASH ARM® Cortex®-M4 32-Bit Microcontroller Kinetis K20 Series 3.3V 169-UFBGA, WLCSP

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MK26FN2M0CAC18R information

NXP MK26FN2M0CAC18R technical specifications, attributes, parameters and parts with similar specifications to NXP MK26FN2M0CAC18R.

  • Type
  • Parameter
  • Factory Lead Time
  • 16 Weeks
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 169-UFBGA, WLCSP
  • Surface Mount
  • YES
  • Operating Temperature
  • -40°C~85°C TA
  • Packaging
  • Tape & Reel (TR)
  • Series
  • Kinetis K20
  • Published
  • 2002
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 169
  • ECCN Code
  • 3A991.A.2
  • HTS Code
  • 8542.31.00.01
  • Subcategory
  • Microcontrollers
  • Technology
  • CMOS
  • Terminal Position
  • BOTTOM
  • Terminal Form
  • BALL
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Supply Voltage
  • 3.3V
  • Terminal Pitch
  • 0.4mm
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • JESD-30 Code
  • R-PBGA-B169
  • Qualification Status
  • Not Qualified
  • Supply Voltage-Max (Vsup)
  • 3.6V
  • Supply Voltage-Min (Vsup)
  • 1.71V
  • Oscillator Type
  • Internal
  • Number of I/O
  • 116
  • Speed
  • 180MHz
  • RAM Size
  • 256K x 8
  • Voltage - Supply (Vcc/Vdd)
  • 1.71V~3.6V
  • uPs/uCs/Peripheral ICs Type
  • MICROCONTROLLER, RISC
  • Core Processor
  • ARM® Cortex®-M4
  • Peripherals
  • DMA, I2S, LVD, POR, PWM, WDT
  • Clock Frequency
  • 50MHz
  • Program Memory Type
  • FLASH
  • Core Size
  • 32-Bit
  • Program Memory Size
  • 2MB 2M x 8
  • Connectivity
  • CANbus, EBI/EMI, I2C, IrDA, SD, SPI, UART/USART, USB, USB OTG
  • Supply Current-Max
  • 106.75mA
  • Bit Size
  • 32
  • Data Converter
  • A/D 5x12b, 6x16b; D/A 2x12b
  • Has ADC
  • YES
  • DMA Channels
  • YES
  • PWM Channels
  • YES
  • DAC Channels
  • YES
  • ROM (words)
  • 2097152
  • CPU Family
  • CORTEX-M4F

Download datasheets and manufacturer documentation for NXP MK26FN2M0CAC18R.

Datasheets:

Environmental Information:

MK26FN2M0CAC18R Description


The MK26FN2M0CAC18R is a Kinetis? K26-180 MHz, Dual High-Speed & Full-Speed USBs, 2MB Flash Microcontrollers (MCUs) based on Arm? Cortex?-M4 Core. The Arm? Cortex?-M4F core is used in the Kinetis? K26 180MHz High-Speed USB MCUs, which are designed for use in applications requiring high memory densities and low power consumption. This family shares the broad enabling and flexibility of the Kinetis portfolio and provides High-Speed USB with an integrated HS USB Physical Transceiver, SDRAM Controller, and Full Speed Crystal-less USB compatibility.



MK26FN2M0CAC18R Features


Ultra-Low-Power

  • Flexible low-power modes with power and clock gating for optimal peripheral activity and recovery times. Run power consumption down to <250 ?A/MH and static power consumption down to 9.0 ?A with full state retention and <6 ?S wakeup. Lowest static mode down to 254 nA (VLLS0).

  • Full memory and analog operation down to 1.71 volts for extended battery life

  • Low-leakage wake-up unit with up to seven internal modules and over 20 pins as wake-up sources in low-leakage stop (LLS) and very low-leakage stop (VLLS) modes

  • Low-power timer for continual system operation in reduced power state

Memory

  • Up to 2 MB flash. Fast access, high reliability with four-level security protection

  • 256 KB of SRAM

Performance

  • Cortex-M4F core running at 180 MHz with single precision floating point unit and 8KB of Cache

  • Up to 32-channel DMA for peripheral and memory servicing with reduced CPU loading and faster system throughput, with asynchronous support in Stop mode.

  • Cross bar switch enables concurrent multi-leader bus accesses, increasing bus bandwidth

  • Independent flash banks allow concurrent code execution and firmware updating with no performance degradation or complex coding routines



MK26FN2M0CAC18R Applications


  • Industrial

  • Air Conditioning (AC)

  • Blood Glucose Management

  • Continuous Positive Airway Pressure Machine (CPAP)

  • Digital Stethoscope

  • Electricity Grid and Distribution

  • Gas Meter

  • Heart Monitors

  • Heat Metering

  • Home Health Gateway

  • Industrial HMI

  • Motor Drives

  • Smart Power Socket and Light Switch

  • Surround View

  • Vital Signs Monitors

  • Water Meter
