NXP LPC54628J512ET180E
NXP LPC54628J512ET180E

NXP LPC54628J512ET180E

Manufacturer No:

LPC54628J512ET180E

Manufacturer:

NXP

Package:

180-TFBGA

Description:

512KB 512K x 8 FLASH ARM® Cortex®-M4 32-Bit Microcontroller LPC546xx Series 1.8V 180-TFBGA

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

LPC54628J512ET180E information

NXP LPC54628J512ET180E technical specifications, attributes, parameters and parts with similar specifications to NXP LPC54628J512ET180E.

  • Type
  • Parameter
  • Factory Lead Time
  • 12 Weeks
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 180-TFBGA
  • Surface Mount
  • YES
  • Operating Temperature
  • -40°C~105°C TA
  • Packaging
  • Tray
  • Series
  • LPC546xx
  • Published
  • 2010
  • JESD-609 Code
  • e8
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 3 (168 Hours)
  • Number of Terminations
  • 180
  • Terminal Finish
  • Tin/Silver/Copper (Sn98.5Ag1.0Cu0.5)
  • Technology
  • CMOS
  • Terminal Position
  • BOTTOM
  • Terminal Form
  • BALL
  • Peak Reflow Temperature (Cel)
  • 260
  • Supply Voltage
  • 1.8V
  • Terminal Pitch
  • 0.8mm
  • Time@Peak Reflow Temperature-Max (s)
  • 30
  • JESD-30 Code
  • S-PBGA-B180
  • Supply Voltage-Max (Vsup)
  • 3.6V
  • Supply Voltage-Min (Vsup)
  • 1.71V
  • Oscillator Type
  • Internal
  • Speed
  • 220MHz
  • RAM Size
  • 200K x 8
  • Voltage - Supply (Vcc/Vdd)
  • 1.71V~3.6V
  • uPs/uCs/Peripheral ICs Type
  • MICROCONTROLLER, RISC
  • Core Processor
  • ARM® Cortex®-M4
  • Peripherals
  • Brown-out Detect/Reset, DMA, I2S, LCD, POR, PWM, WDT
  • Clock Frequency
  • 25MHz
  • Program Memory Type
  • FLASH
  • Core Size
  • 32-Bit
  • Program Memory Size
  • 512KB 512K x 8
  • Connectivity
  • CANbus, Ethernet, I2C, SPI, UART/USART, USB
  • Bit Size
  • 32
  • Data Converter
  • A/D 12x12b
  • Has ADC
  • YES
  • DMA Channels
  • YES
  • PWM Channels
  • YES
  • DAC Channels
  • NO
  • Address Bus Width
  • 21
  • EEPROM Size
  • 16K x 8
  • On Chip Program ROM Width
  • 8
  • External Data Bus Width
  • 16
  • Length
  • 12mm
  • Height Seated (Max)
  • 1.2mm

Download datasheets and manufacturer documentation for NXP LPC54628J512ET180E.

Datasheets:

Environmental Information:

LPC54628J512ET180E Description


A family of ARM Cortex-M4-based microcontrollers for embedded applications, the LPC54628J512ET180E has a comprehensive peripheral set, very low power consumption, and improved debug tools.

A 32-bit core, the ARM Cortex-M4 provides system improvements like reduced power usage, improved debug tools, and a high level of support block integration. The Harvard design, 3-stage pipeline, separate local instruction and data buses, third bus for peripherals, and internal prefetch unit with capability for speculative branching are all features of the ARM Cortex-M4 CPU. Single-cycle digital signal processing and SIMD instructions are supported by the ARM Cortex-M4 processor. The core has a hardware floating-point processor.



LPC54628J512ET180E Features


  • Single power supply 1.71 V to 3.6 V.

  • Power-On Reset (POR).

  • Brown-Out Detect (BOD) with separate thresholds for interrupt and forced reset.

  • JTAG boundary scan supported.

  • 128 bit unique device serial number for identification.

  • Operating temperature range from -40 °C to +105 °C.

  • Available in TFBGA180, TFBGA100, LQFP208, and LQFP100 packages.

  • ARM Cortex-M4 core (version r0p1):

  • ARM Cortex-M4 processor, running at a frequency of up to 220 MHz.

  • The LPC5460x/61x devices operate at CPU frequencies of up to 180 MHz. The LPC54628 device operates at CPU frequencies of up to 220 MHz.

  • Floating Point Unit (FPU) and Memory Protection Unit (MPU).

  • ARM Cortex-M4 built-in Nested Vectored Interrupt Controller (NVIC).

  • Non-maskable Interrupt (NMI) input with a selection of sources.

  • Serial Wire Debug (SWD) with six instruction breakpoints, two literal comparators, and four watch points. Includes Serial Wire Output and ETM Trace for enhanced debug capabilities, and a debug timestamp counter.

  • System tick timer.



LPC54628J512ET180E Applications


  • Automobile engine control systems

  • Implantable medical devices

  • Remote controls

  • Office machines

  • Appliances

  • Power tools


User Guide
