Harwin M80-6652642
Harwin M80-6652642

Harwin M80-6652642

Manufacturer No:

M80-6652642

Manufacturer:

Harwin

Package:

Description:

Datamate L-Tek Series 2-Row Plug Solder Brass Tube Surface Mount, Right Angle Gold Polyphenylene Sulfide (PPS), Glass Filled 26-Position Board to Board or Cable 0.235 5.97mm Height

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

M80-6652642 information

Harwin M80-6652642 technical specifications, attributes, parameters and parts with similar specifications to Harwin M80-6652642.

  • Type
  • Parameter
  • Factory Lead Time
  • 13 Weeks
  • Contact Material
  • Brass
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount, Right Angle
  • Contact Shape
  • Circular
  • Insulation Material
  • Polyphenylene Sulfide (PPS), Glass Filled
  • Operating Temperature
  • -55°C~125°C
  • Packaging
  • Tube
  • Series
  • Datamate L-Tek
  • Published
  • 2006
  • JESD-609 Code
  • e3
  • Feature
  • Strain Relief Clips
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Solder
  • Connector Type
  • Plug
  • Number of Positions
  • 26
  • Number of Rows
  • 2
  • Gender
  • Male
  • Voltage - Rated
  • 800V
  • Additional Feature
  • ROHS COMPLIANT
  • Fastening Type
  • Latch Holder
  • Subcategory
  • Headers and Edge Type Connectors
  • MIL Conformance
  • NO
  • DIN Conformance
  • NO
  • IEC Conformance
  • NO
  • Filter Feature
  • NO
  • Contact Type
  • Male Pin
  • Mixed Contacts
  • NO
  • Option
  • GENERAL PURPOSE
  • Current Rating (Amps)
  • 2.2A
  • Total Number of Contacts
  • 26
  • Insulation Height
  • 0.235 5.97mm
  • Style
  • Board to Board or Cable
  • Number of Positions Loaded
  • All
  • Pitch - Mating
  • 0.079 2.00mm
  • Insulation Color
  • Black
  • Number of Conductors
  • ONE
  • Reference Standard
  • UL
  • Reliability
  • COMMERCIAL
  • Body Length or Diameter
  • 1.163 inch
  • Row Spacing - Mating
  • 0.079 (2.00mm)
  • Shrouding
  • Shrouded - 4 Wall
  • Number Of PCB Rows
  • 2
  • Contact Finish - Post
  • Tin
  • PCB Contact Pattern
  • RECTANGULAR

Download datasheets and manufacturer documentation for Harwin M80-6652642.

Datasheets:

M80-6652642 Overview


It comes in Plug packaging.The device's mounting type is Surface Mount, Right Angle.In order to package the product, a Tube case is used.It belongs to the Datamate L-Tek Series of products.In addition, there are other features such as ROHS COMPLIANT, to mention only a few.Its Strain Relief Clips feature renders it more powerful in many ways.The part is mounted by Surface Mount.The device runs in -55°C~125°C Operating Temperature.
