Renesas HC5513BIM

Manufacturer No:

HC5513BIM

Manufacturer:

Renesas

Package:

DIP

Description:

28 Terminations Telecom device 1 Circuits 1 Functions

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

HC5513BIM information

Renesas HC5513BIM technical specifications, attributes, parameters and parts with similar specifications to Renesas HC5513BIM.

Type
Parameter

Mount
Through Hole

Package / Case
DIP

Published
2000

JESD-609 Code
e0

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
28

Terminal Finish
Tin/Lead (Sn/Pb)

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Subcategory
Analog Transmission Interfaces

Technology
BIPOLAR

Terminal Position
QUAD

Terminal Form
J BEND

Peak Reflow Temperature (Cel)
225

Number of Functions
1

Supply Voltage
5V

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

JESD-30 Code
S-PQCC-J28

Qualification Status
Not Qualified

Power Supplies
+-5V

Temperature Grade
INDUSTRIAL

Number of Circuits
1

Power Dissipation-Max
1.5W

Operating Supply Current
2.25mA

Neg Supply Voltage-Nom
-5V

Battery Feed
CONSTANT CURRENT

Hybrid
2-4 CONVERSION

Battery Supply
-28 V

Height Seated (Max)
4.57mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Renesas HC5513BIM.

Datasheets:

intersil-hc5513bim-datasheets-3777.pdf

HC5513BIM Overview

DIP package is used to save board space.This telecom IC is composed of 1 circuits.Telecom switching is mounted in the way of Through Hole.There are 28 terminations can be found in telecom switching configuration.The supply voltage it operates with is 5V.It adopts SLIC as its telecom IC type.Telecom product operates with the supply current of 2.25mA to provide much flexibility for designers.Telecommunications device belongs to the subcategory of Analog Transmission Interfaces.The temperature is set at the minimum value of -40°C to ensure normal operation.The temperature is set at the maximum value of 85°C to ensure normal operation.Telecommunications device is configured wit h 1 functions when designing.

HC5513BIM Features

Available in the DIP package
SLIC as telecom IC type
Operating supply current of 2.25mA

HC5513BIM Applications

There are a lot of Intersil (Renesas Electronics America)
HC5513BIM Telecom applications.

High-Density T1/E1/J1 interfaces for Multiplexers
Switches
LAN Routers
Digital Modems
SONET/SDH terminal
Add/Drop multiplexers (ADMs)
T1/E1/J1 add/drop multiplexers (MUX)
Channel Service Units (CSUs): T1/E1/J1
Fractional T1/E1/J1
BITS Timing
