United Chemi-Con EKMG160ELL103MMP1S

Manufacturer No:

EKMG160ELL103MMP1S

Manufacturer:

United Chemi-Con

Package:

Radial, Can

Description:

KMG 10000?F Capacitor ±20% Bulk Through Hole 2.06A 0.709Dia 18.00mm -55°C~105°C Polar 7.5mm Radial, Can

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

EKMG160ELL103MMP1S information

United Chemi-Con EKMG160ELL103MMP1S technical specifications, attributes, parameters and parts with similar specifications to United Chemi-Con EKMG160ELL103MMP1S.

Type
Parameter

Factory Lead Time
16 Weeks

Mount
Through Hole

Mounting Type
Through Hole

Package / Case
Radial, Can

Dielectric Material
Aluminium

Operating Temperature
-55°C~105°C

Packaging
Bulk

Series
KMG

Published
2010

Size / Dimension
0.709Dia 18.00mm

Tolerance
±20%

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
Not Applicable

Termination
Radial

Applications
General Purpose

Capacitance
10000?F

Voltage - Rated DC
16V

Lead Pitch
7.5mm

Lead Spacing
0.295 7.50mm

Lead Diameter
800 ?m

Lifetime @ Temp
1000 Hrs @ 105°C

Ripple Current
2.06A

Polarization
Polar

Ripple Current @ Low Frequency
2.06A @ 120Hz

Ripple Current @ High Frequency
2.2248A @ 100kHz

Diameter
18mm

Height
35.5mm

Height Seated (Max)
1.457 37.00mm

REACH SVHC
Unknown

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for United Chemi-Con EKMG160ELL103MMP1S.

Datasheets:

unitedchemicon-ekmg500ell221mjc5s-datasheets-5821.pdf

EKMG160ELL103MMP1S Overview

Ripple current at full charge is 2.2248A @ 100kHz.It is 2.06A @ 120Hz at the lowest charge for ripple current.Seating height (Max) should be kept below 1.457 37.00mm.Voltage - Rated DC - is 16V.It is recommended that the operating temperature be kept at -55°C~105°C to achieve high efficiency.

EKMG160ELL103MMP1S Features

the ripple current is 2.2248A @ 100kHz.
the ripple current is 2.06A @ 120Hz.
voltage - Rated DC of 16V
an operating temperature of -55°C~105°C

EKMG160ELL103MMP1S Applications

There are a lot of United Chemi-Con
EKMG160ELL103MMP1S applications of aluminum electrolytic capacitors.

Power supplies
Computer motherboards
Uninterruptible power supplies
Frequency converters
Computer
Telecommunication
Industrial systems
Smoothing and filtering applications
Standard and switched mode power supplies
Energy storage in pulse systems
