ROHM BR24L16-W

Manufacturer No:

BR24L16-W

Manufacturer:

ROHM

Package:

8-DIP (0.300, 7.62mm)

Description:

2/5V V Through Hole 8 Pin Memory IC BR24L16 16 kb kb 9.3mm mm

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

BR24L16-W information

ROHM BR24L16-W technical specifications, attributes, parameters and parts with similar specifications to ROHM BR24L16-W.

Type
Parameter

Factory Lead Time
10 Weeks

Mount
Through Hole

Mounting Type
Through Hole

Package / Case
8-DIP (0.300, 7.62mm)

Number of Pins
8

Operating Temperature
-40°C~85°C TA

Packaging
Tube

Published
2011

JESD-609 Code
e3/e2

Pbfree Code
yes

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
8

ECCN Code
EAR99

Terminal Finish
TIN/TIN COPPER

Technology
CMOS

Voltage - Supply
1.8V~5.5V

Terminal Position
DUAL

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Supply Voltage
2.5V

Terminal Pitch
2.54mm

Time@Peak Reflow Temperature-Max (s)
10

Base Part Number
BR24L16

Qualification Status
Not Qualified

Supply Voltage-Max (Vsup)
5.5V

Power Supplies
2/5V

Interface
2-Wire, I2C, Serial

Memory Size
16Kb 2K x 8

Memory Type
Non-Volatile

Operating Mode
SYNCHRONOUS

Clock Frequency
400kHz

Supply Current-Max
0.002mA

Access Time
900 ns

Memory Format
EEPROM

Memory Interface
I2C

Memory Width
8

Write Cycle Time - Word, Page
5ms

Density
16 kb

Standby Current-Max
0.000002A

Serial Bus Type
I2C

Endurance
1000000 Write/Erase Cycles

Write Cycle Time-Max (tWC)
5ms

Data Retention Time-Min
40

Write Protection
HARDWARE

I2C Control Byte
1010MMMR

Length
9.3mm

Download datasheets and manufacturer documentation for ROHM BR24L16-W.

BR24L16-W Overview

A Non-Volatile-type memory can be classified as the memory type of this device. In addition, memory ics is available in a Tube case as well. Embedded in the 8-DIP (0.300, 7.62mm) case, memory ics is a single file. On the chip, there is an 16Kb 2K x 8 memory, which is the size of the chip's memory. There is a EEPROM-format memory used in this device, which is the memory format used by mainstream devices. Featuring an extended operating temperature range of -40°C~85°C TA, this device allows it to be used in a variety of demanding applications. The device is capable of handling a supply voltage of 1.8V~5.5V volts. The recommended mounting type for memory ics is Through Hole. A total of 8 terminations have been planted on the chip. The comprehensive working procedure of this part involves 1 functions. In order to power this memory device, 2.5V will be necessary. A clock frequency rotation within 400kHz is used for the ic memory chip to rotate data. Similar parts are frequently selected using the ic memory chip's base part number, BR24L16. A 8-pin package containing this memory device is used to house this device. The memory device in question has 8 pins, thus indicating that it has 8 memory locations that can be accessed. The memory chip utilizes a straightforward, high-efficiency mounting method, Through Hole mounting. As for power supplies, this memory chip requires just 2/5V . Its I2C-type serial bus helps transfer data to the CPU efficiently. In order to operate your device, you will need to provide a maximum supply current of 0.002mA.

BR24L16-W Features

Package / Case: 8-DIP (0.300, 7.62mm)
8 Pins

BR24L16-W Applications

There are a lot of ROHM Semiconductor
BR24L16-W Memory applications.

supercomputers
telecommunications
workstations,
DVD disk buffer
data buffer
nonvolatile BIOS memory
Camcorders
embedded logic
eDRAM
graphics card
