MAXLINEAR XR17C158CV

Manufacturer No:

XR17C158CV

Manufacturer:

MAXLINEAR

Package:

LQFP

Description:

5V V 1.6mm mm 20mm mm Interface - UARTs (Universal Asynchronous Receiver Transmitter) 20mm mm CMOS 144 NOT SPECIFIED 144

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

XR17C158CV information

MAXLINEAR XR17C158CV technical specifications, attributes, parameters and parts with similar specifications to MAXLINEAR XR17C158CV.

Type
Parameter

Mount
Surface Mount

Package / Case
LQFP

Number of Pins
144

JESD-609 Code
e0

Number of Terminations
144

Terminal Finish
Tin/Lead (Sn/Pb)

Max Operating Temperature
70°C

Min Operating Temperature
0°C

Additional Feature
ALSO OPERATES AT 3.3V SUPPLY

Subcategory
Serial IO/Communication Controllers

Technology
CMOS

Terminal Position
QUAD

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Supply Voltage
5V

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Pin Count
144

Qualification Status
Not Qualified

Power Supplies
5V

Temperature Grade
COMMERCIAL

Number of Channels
8

Max Supply Voltage
5.5V

Min Supply Voltage
4.5V

uPs/uCs/Peripheral ICs Type
SERIAL IO/COMMUNICATION CONTROLLER, SERIAL

Clock Frequency
50MHz

Data Rate
6.25 Mbps

Address Bus Width
32

Boundary Scan
NO

Low Power Mode
YES

External Data Bus Width
32

Number of Serial I/Os
8

Bus Compatibility
PCI

Communication Protocol
ASYNC, BIT

Data Encoding/Decoding Method
NRZ

Length
20mm

Height Seated (Max)
1.6mm

Width
20mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for MAXLINEAR XR17C158CV.

Datasheets:

exar-xr17c158cv-datasheets-8709.pdf

XR17C158CV Overview

In addition, it is available in the cost-effective package LQFP.In order to transmit data, there are 8 channels available.There is a SERIAL IO/COMMUNICATION CONTROLLER, SERIAL used as the type of uPS/uCs/peripheral ICs.Configured with 144 terminations.The device operates at 5V voltage.Data communication is handled by 8 serial I/Os.UART is a type of 144-pin integrated circuUART.IC clock frequency is set to 50MHz.UART has been grouped under the subcategory Serial IO/Communication Controllers on account of UARTs similarUARTies.Ideally, the operating temperature should not exceed 0°C in order to ensure long-term performance.In order to ensure the normal functioning of the system for long periods of time, the operating temperature should not exceed 70°C.Initially, it will be configured with 144 pins.Using the Surface Mount method, it is mounted.Keeping the supply voltage below 5.5V will ensure reliability.Supply voltages above 4.5V are known to ensure reliability.In the case of 5V power supplies, it is reliable and efficient to use by electronic designers.Additionally, it is also able to perform ALSO OPERATES AT 3.3V SUPPLY and other operations as well.

XR17C158CV Features

8 serial I/Os
Clock frequency of 50MHz
Power supplies of 5V
ALSO OPERATES AT 3.3V SUPPLY

XR17C158CV Applications

There are a lot of Exar Corporation
XR17C158CV UARTs applications.

Handheld Terminal
Personal Digital Assistants
Cellular Phones DataPort
Wireless Infrared Data Communications Systems
Handheld Terminals and Tablets
Handheld Computers
Wireless Portable Point-of-Sale Terminals
GPS Devices
Personal Digital Assistants Modules
Battery Operated Instruments
