OMRON XF2B-2345-31A
OMRON XF2B-2345-31A

OMRON XF2B-2345-31A

Manufacturer No:

XF2B-2345-31A

Manufacturer:

OMRON

Package:

Description:

XF2B Series FPC Contacts, Top and Bottom Tape & Reel (TR) 0.012 0.30mm Solder 23 Positions Surface Mount, Right Angle Gold -30°C~85°C 0.2A

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

XF2B-2345-31A information

OMRON XF2B-2345-31A technical specifications, attributes, parameters and parts with similar specifications to OMRON XF2B-2345-31A.

  • Type
  • Parameter
  • Factory Lead Time
  • 15 Weeks
  • Contact Material
  • Copper Alloy
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount, Right Angle
  • Housing Material
  • Liquid Crystal Polymer (LCP), Halogen Free
  • Actuator Material
  • Liquid Crystal Polymer (LCP), Halogen Free
  • Operating Temperature
  • -30°C~85°C
  • Packaging
  • Tape & Reel (TR)
  • Series
  • XF2B
  • Published
  • 2004
  • JESD-609 Code
  • e4
  • Pbfree Code
  • yes
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • Not Applicable
  • Termination
  • Solder
  • ECCN Code
  • EAR99
  • Number of Positions
  • 23
  • Number of Rows
  • 1
  • Additional Feature
  • STAGGERED CONFIGURATION
  • Subcategory
  • Headers and Edge Type Connectors
  • MIL Conformance
  • NO
  • DIN Conformance
  • NO
  • IEC Conformance
  • NO
  • Filter Feature
  • NO
  • Option
  • GENERAL PURPOSE
  • Current Rating (Amps)
  • 0.2A
  • Pitch
  • 0.012 0.30mm
  • Total Number of Contacts
  • 23
  • Orientation
  • Right Angle
  • Depth
  • 5.2mm
  • Reach Compliance Code
  • unknown
  • Current Rating
  • 200mA
  • Reference Standard
  • UL
  • Contact Finish
  • Gold
  • Reliability
  • COMMERCIAL
  • Number Of PCB Rows
  • 2
  • Lead Pitch
  • 300?m
  • PCB Contact Pattern
  • STAGGERED
  • Body Breadth
  • 0.047 inch
  • Contact Gender
  • FEMALE
  • UL Flammability Code
  • 94V-0
  • Housing Color
  • Natural
  • Contact Style
  • BELLOWED TYPE
  • Contact Resistance
  • 50mOhm
  • Max Voltage Rating (AC)
  • 50V
  • Max Current Rating
  • 200mA
  • Dielectric Withstanding Voltage
  • 250VAC V

Download datasheets and manufacturer documentation for OMRON XF2B-2345-31A.

Datasheets:

Other Related Documents:

XF2B-2345-31A Overview


This device has a Surface Mount, Right Angle mounting type.An orange Tape & Reel (TR) case is used to package the product.Specifically, it is one of the products in the XF2B Series.Other features include STAGGERED CONFIGURATION, to name just a few.There is a mounting hole at Surface Mount.Devices operate at -30°C~85°C operating temperatures.
