W171DIP-12 Information
Magnecraft W171DIP-12 technical specifications, attributes, parameters and parts with similar specifications to Magnecraft W171DIP-12.
- Type
- Parameter
- Manufacturer Part Number
- W171DIP-12
- RoHS Status
- RoHS Compliant
- Part Life Cycle Code
- Active
- Ihs Manufacturer
- SCHNEIDER ELECTRIC SA
- Reach Compliance Code
- unknown
- ECCN Code
- EAR99
- HTS Code
- 8536.49.00.50
- Manufacturer
- Schneider Electric
- Risk Rank
- 5.55
- Body Breadth
- 7.37 mm
- Type
- Parameter
- Body Height
- 7.62 mm
- Body Length or Diameter
- 20.14 mm
- Coil Resistance
- 500 ?
- Coil Voltage-Nom
- 5 V
- Coil/Input Supply Type
- DC
- Contact Current(AC)-Max
- 0.5 A
- Contact Current(DC)-Max
- 0.5 A
- Contact Voltage(AC)-Max
- 120 V
- Contact Voltage(DC)-Max
- 200 V
- Contact/Output Supply Type
- AC/DC
Download datasheets and manufacturer documentation for Magnecraft W171DIP-12.
No product details available
W171DIP-12 FAQ
Can I request a quote for W171DIP-12?
W171DIP-12 from Magnecraft is ready for RFQ submission. Send your target quantity and requirements, and AIChipLink will check current availability, lead time, and quantity-based pricing.
Why is pricing not shown as a fixed value for W171DIP-12?
The final price for W171DIP-12 depends on requested quantity, supply conditions, date code, package option, and destination. An RFQ lets us return the current market quote for your order.
Which specifications should I review for W171DIP-12?
W171DIP-12 is a Magnecraft Relay Sockets part. Key details include Dielectric Strength Between Coil and Contacts: 500 Vrms and Dielectric Strength Between Open Contacts: 150 Vrms; contact us if you need the specifications verified before sourcing.
When will I receive a quotation for W171DIP-12?
After you submit the RFQ for W171DIP-12, our sales team typically replies within 24 hours with availability, unit pricing, lead time, shipping choices, and possible substitutes.
What is the expected shipping time for W171DIP-12?
Once stock for W171DIP-12 is confirmed, available inventory can generally ship within 1–2 business days. The final schedule depends on quantity, warehouse source, and delivery address.
Can AIChipLink help find alternatives to W171DIP-12?
Yes. If W171DIP-12 is unavailable, end-of-life, or outside your schedule, we can review comparable Magnecraft Relay Sockets parts and compatible replacement options.
