TI VSP2582RHN

Manufacturer No:

VSP2582RHN

Manufacturer:

Package:

36-VFQFN

Description:

12 Bit 0.5mm AFE VSP2582 3V 36-VFQFN

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

VSP2582RHN information

TI VSP2582RHN technical specifications, attributes, parameters and parts with similar specifications to TI VSP2582RHN.

Type
Parameter

Lifecycle Status
ACTIVE (Last Updated: 1 day ago)

Factory Lead Time
6 Weeks

Mount
Surface Mount

Package / Case
36-VFQFN

Number of Pins
36

Packaging
Tray

JESD-609 Code
e4

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
36

Terminal Finish
Nickel/Palladium/Gold (Ni/Pd/Au)

Max Operating Temperature
85°C

Min Operating Temperature
-25°C

Max Power Dissipation
85mW

Terminal Position
QUAD

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Supply Voltage
3V

Terminal Pitch
0.5mm

Base Part Number
VSP2582

Pin Count
36

Operating Supply Voltage
3V

Temperature Grade
OTHER

Interface
Serial

Max Supply Voltage
3.6V

Min Supply Voltage
2.7V

Analog IC - Other Type
ANALOG CIRCUIT

Number of Bits
12

Resolution
1.5 B

Sampling Rate
36 Msps

Voltage - Supply, Analog
2.7V~3.6V

Voltage - Supply, Digital
2.7V~3.6V

Height
950?m

Length
6mm

Width
6mm

Thickness
900?m

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for TI VSP2582RHN.

PCN Design/Specification:

texasinstruments-pcm2906cdb-pcndesignspecification-1585.pdf

VSP2582RHN Overview
