TI UC3178QP

Manufacturer No:

UC3178QP

Manufacturer:

Package:

28-LCC (J-Lead)

Description:

450mA per Channel 50μA Instrumentational OP Amps 3V~15V UC3178 28 Pins 28-LCC (J-Lead)

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

UC3178QP information

TI UC3178QP technical specifications, attributes, parameters and parts with similar specifications to TI UC3178QP.

Type
Parameter

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
28-LCC (J-Lead)

Number of Pins
28

Operating Temperature
0°C~70°C

Packaging
Tube

JESD-609 Code
e4

Pbfree Code
yes

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
28

ECCN Code
EAR99

Terminal Finish
Nickel/Palladium/Gold (Ni/Pd/Au)

Subcategory
Motion Control Electronics

Technology
BIPOLAR

Terminal Position
QUAD

Terminal Form
J BEND

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Supply Voltage
12V

Base Part Number
UC3178

Pin Count
28

Output Voltage
20V

Supply Voltage-Max (Vsup)
15V

Number of Circuits
2

Analog IC - Other Type
VOICE COIL MOTOR CONTROLLER

Operating Supply Current
13mA

Output Current
450mA

Slew Rate
1V/μs

Amplifier Type
Power

Current - Input Bias
50μA

Voltage - Supply, Single/Dual (±)
3V~15V

Output Current per Channel
450mA

Input Offset Voltage (Vos)
12mV

Gain Bandwidth Product
2MHz

Supply Current-Max (Isup)
18mA

Length
11.505mm

Height Seated (Max)
4.57mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free
