Manufacturer No:

TN4033A

Manufacturer:

ONSEMI

Package:

TO-226-3, TO-92-3 (TO-226AA)

Description:

PNP -55°C~150°C TJ 50nA ICBO 1 Elements 3 Terminations SILICON PNP TO-226-3, TO-92-3 (TO-226AA) Bulk Through Hole

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

TN4033A information

ONSEMI TN4033A technical specifications, attributes, parameters and parts with similar specifications to ONSEMI TN4033A.

  • Type
  • Parameter
  • Mount
  • Through Hole
  • Mounting Type
  • Through Hole
  • Package / Case
  • TO-226-3, TO-92-3 (TO-226AA)
  • Number of Pins
  • 3
  • Weight
  • 250mg
  • Transistor Element Material
  • SILICON
  • Operating Temperature
  • -55°C~150°C TJ
  • Packaging
  • Bulk
  • JESD-609 Code
  • e3
  • Pbfree Code
  • yes
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 3
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Matte Tin (Sn)
  • Voltage - Rated DC
  • -80V
  • Max Power Dissipation
  • 1W
  • Terminal Position
  • BOTTOM
  • Current Rating
  • -1A
  • Number of Elements
  • 1
  • Element Configuration
  • Single
  • Power Dissipation
  • 1W
  • Transistor Application
  • SWITCHING
  • Polarity/Channel Type
  • PNP
  • Collector Emitter Voltage (VCEO)
  • 80V
  • Max Collector Current
  • 1A
  • DC Current Gain (hFE) (Min) @ Ic, Vce
  • 100 @ 100mA 5V
  • Current - Collector Cutoff (Max)
  • 50nA ICBO
  • Vce Saturation (Max) @ Ib, Ic
  • 500mV @ 50mA, 500mA
  • Collector Emitter Breakdown Voltage
  • 80V
  • Collector Base Voltage (VCBO)
  • 80V
  • Emitter Base Voltage (VEBO)
  • 5V
  • hFE Min
  • 100
  • Turn Off Time-Max (toff)
  • 400ns
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for ONSEMI TN4033A.

Datasheets:

ReachStatement:

TN4033A Overview


DC current gain in this device equals 100 @ 100mA 5V, which is the ratio of the base current to the collector current.Saturation of VC means the Ic value is at its maximum, so vce saturation (Max) is 500mV @ 50mA, 500mA.An emitter's base voltage can be kept at 5V to gain high efficiency.Current rating refers to the maximum current a fuse can carry for an indefinite period without deteriorating substantially, and this device has a -1A current rating.In extreme cases, the collector current can be as low as 1A volts.

TN4033A Features


the DC current gain for this device is 100 @ 100mA 5V
the vce saturation(Max) is 500mV @ 50mA, 500mA
the emitter base voltage is kept at 5V
the current rating of this device is -1A


TN4033A Applications


There are a lot of ON Semiconductor
TN4033A applications of single BJT transistors.


  • Inverter
  • Interface
  • Driver
  • Muting
