Renesas ISL8118IRZ-T

Manufacturer No:

ISL8118IRZ-T

Manufacturer:

Renesas

Package:

QFN EP

Description:

28 Terminals 28-Pin DC to DC converter IC SWITCHING CONTROLLER 1 Outputs 2MHz

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL8118IRZ-T information

Renesas ISL8118IRZ-T technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL8118IRZ-T.

Type
Parameter

Factory Lead Time
15 Weeks

Mount
Surface Mount

Package / Case
QFN EP

Number of Pins
28

Packaging
Tape & Reel (TR)

Published
2001

JESD-609 Code
e3

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
28

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Subcategory
Switching Regulator or Controllers

Terminal Position
QUAD

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
40

Pin Count
28

Number of Outputs
1

Qualification Status
Not Qualified

Temperature Grade
INDUSTRIAL

Analog IC - Other Type
SWITCHING CONTROLLER

Current - Output
30A

Frequency (Max)
2MHz

Voltage - Output
20V

Input Voltage (Min)
3.3V

Control Mode
VOLTAGE-MODE

Frequency - Switching
2MHz

Control Technique
PULSE WIDTH MODULATION

Switcher Configuration
PUSH-PULL

Max Duty Cycle
100 %

Duty Cycle (Max)
100 %

Length
5mm

Width
5mm

RoHS Status
RoHS Compliant
