NEXPERIA TL431FDT

Manufacturer No:

TL431FDT

Manufacturer:

NEXPERIA

Package:

TSOP,

Description:

Three Terminal Voltage Reference

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

TL431FDT information

NEXPERIA TL431FDT technical specifications, attributes, parameters and parts with similar specifications to NEXPERIA TL431FDT.

Type
Parameter

RoHS Status
RoHS Compliant

Part Life Cycle Code
Active

Ihs Manufacturer
NEXPERIA

Package Description
TSOP,

Reach Compliance Code
compliant

ECCN Code
EAR99

HTS Code
8542.39.00.01

Date Of Intro
2017-02-01

Samacsys Manufacturer
Nexperia

Additional Feature
PROGRAMMABLE OUTPUT VOLTAGE UP TO 36 V

Analog IC - Other Type
TWO TERMINAL VOLTAGE REFERENCE

JESD-30 Code
R-PDSO-G3

JESD-609 Code
e3

Length
2.9 mm

Moisture Sensitivity Level
1

Number of Functions
1

Number of Outputs
1

Number of Terminals
3

Operating Temperature-Max
125 °C

Operating Temperature-Min
-40 °C

Output Voltage-Max
2.55 V

Output Voltage-Min
2.44 V

Output Voltage-Nom
2.495 V

Package Body Material
PLASTIC/EPOXY

Package Equivalence Code
TO-236

Package Shape
RECTANGULAR

Package Style
SMALL OUTLINE, THIN PROFILE

Peak Reflow Temperature (Cel)
260

Seated Height-Max
1.1 mm

Supply Voltage-Max (Vsup)
36 V

Supply Voltage-Min (Vsup)
2.495 V

Surface Mount
YES

Temp Coef of Voltage-Max
82.589 ppm/°C

Temperature Grade
AUTOMOTIVE

Terminal Finish
TIN

Terminal Form
GULL WING

Terminal Pitch
0.95 mm

Terminal Position
DUAL

Time@Peak Reflow Temperature-Max (s)
30

Trim/Adjustable Output
YES

Width
1.3 mm

Download datasheets and manufacturer documentation for NEXPERIA TL431FDT.

Datasheets:

NEXP-S-A0020730608-1.pdf

TL431FDT Overview

The reference voltage makes use of the handy SOT-23 package.This part is used as a voltage reference and has a Adjustable control.There are various functions associated with terminations 3.Parts are coupled with analog ICs.A voltage of 2.495V is output as a result of the test statistics.There is 1 need to generate more than 1 outputs.The voltage reference ic has settled 3 pins.Inputs of 100mA are compatible with the reference voltage.The application is suitable for Surface Mount.There is 100mA way the voltage reference ic can deliver an output current higher than 100mA.In terms of maximum output voltage, it is equal to 36V.2.495V is the lowest voltage the voltage reference ic can output.Users should constrain the voltage correspondingly since the part can only accept 37V input voltage.It should operate at a temperature 125°C higher than 125°C.Temperatures as low as -40°C can be tolerated by it.Voltage is output at 2.5V.Do the parts contain Substances of Very High Concern (SVHC)?A reference voltage of 36V is provided by this voltage reference ic.

TL431FDT Features

THREE TERMINAL VOLTAGE REFERENCE Analog IC
Max Output Voltage: 37V
Voltage Reference: 36V

TL431FDT Applications

There are a lot of Nexperia
TL431FDT Voltage Reference applications.

Smart industrial transmitters
PCMCIA cards
Automotive
3 V/5 V, 8-bit to 12-bit data converters
Precision data acquisition systems
High resolution converters
Industrial process control systems
Precision instruments
Notebook Computers
Cell Phones
