TOSHIBA TB67Z800FTG,EL

Manufacturer No:

TB67Z800FTG,EL

Manufacturer:

TOSHIBA

Package:

36-VFQFN Exposed Pad

Description:

Tape & Reel (TR) 36-VFQFN Exposed Pad Logic 5.5V~22V Surface Mount -40°C~105°C TA General Purpose Half Bridge (3) Inductive, Capacitive 5.5V~22V

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

TB67Z800FTG,EL information

TOSHIBA TB67Z800FTG,EL technical specifications, attributes, parameters and parts with similar specifications to TOSHIBA TB67Z800FTG,EL.

Type
Parameter

Factory Lead Time
12 Weeks

Mounting Type
Surface Mount

Package / Case
36-VFQFN Exposed Pad

Operating Temperature
-40°C~105°C TA

Packaging
Tape & Reel (TR)

Part Status
Active

Applications
General Purpose

Voltage - Supply
5.5V~22V

Interface
Logic

Output Configuration
Half Bridge (3)

Voltage - Load
5.5V~22V

Current - Output / Channel
3A

Fault Protection
Current Limiting, Over Temperature, Shoot-Through, UVLO

Load Type
Inductive, Capacitive

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for TOSHIBA TB67Z800FTG,EL.

TB67Z800FTG,EL Overview

Tape & Reel (TR) is used for packaging.The 36-VFQFN Exposed Pad package includes H bridge to save money.The supply voltage of 5.5V~22V can improve reliabilbridge drivery.In the way of Surface Mount, H bridge circuit is mounted.Motor driver H bridge's operating temperature enables -40°C~105°C TA to function normally.Among H bridge motor drivers many uses, H bridge motor driver can be found in General Purpose as well.
