MAXLINEAR ST16C554DIQ64TR-F

Manufacturer No:

ST16C554DIQ64TR-F

Manufacturer:

MAXLINEAR

Package:

LQFP-64

Description:

Serial I/O Controller, PQFP64

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ST16C554DIQ64TR-F information

MAXLINEAR ST16C554DIQ64TR-F technical specifications, attributes, parameters and parts with similar specifications to MAXLINEAR ST16C554DIQ64TR-F.

Type
Parameter

RoHS Status
RoHS Compliant

Part Life Cycle Code
Transferred

Ihs Manufacturer
EXAR CORP

Package Description
LQFP-64

Reach Compliance Code
compliant

HTS Code
8542.31.00.01

Samacsys Manufacturer
EXAR

Additional Feature
ALSO OPERATES AT 2.97 V MINIMUM SUPPLY

Address Bus Width
3

Boundary Scan
NO

Clock Frequency-Max
24 MHz

Communication Protocol
ASYNC, BIT

Data Transfer Rate-Max
0.1875 MBps

External Data Bus Width
8

JESD-30 Code
S-PQFP-G64

JESD-609 Code
e3

Length
10 mm

Low Power Mode
NO

Number of Serial I/Os
4

Number of Terminals
64

Operating Temperature-Max
85 °C

Operating Temperature-Min
-40 °C

Package Body Material
PLASTIC/EPOXY

Package Code
LFQFP

Package Shape
SQUARE

Package Style
FLATPACK, LOW PROFILE, FINE PITCH

Qualification Status
Not Qualified

Seated Height-Max
1.6 mm

Supply Voltage-Max
5.5 V

Supply Voltage-Min
4.5 V

Supply Voltage-Nom
5 V

Surface Mount
YES

Technology
CMOS

Temperature Grade
INDUSTRIAL

Terminal Finish
Matte Tin (Sn)

Terminal Form
GULL WING

Terminal Pitch
0.5 mm

Terminal Position
QUAD

Width
10 mm

uPs/uCs/Peripheral ICs Type
SERIAL IO/COMMUNICATION CONTROLLER, SERIAL

Download datasheets and manufacturer documentation for MAXLINEAR ST16C554DIQ64TR-F.

ST16C554DIQ64TR-F Overview

There is a cost-effective LQFP package available for this product.The transmission of data takes place over 4 channels.For packaging purposes, Tape & Reel (TR) is used.The type SERIAL IO/COMMUNICATION CONTROLLER, SERIAL is used to identify the uPs/uCs/Peripheral ICs on the board.Configuration of this device involves 64 terminations.For its operation, it requires a supply voltage of 5V.Data is communicated via 4 serial I/Os.In light of numerous similarities, it is included in the subcategory of Serial IO/Communication Controllers.UART is recommended that the operating temperature does not exceed -40°C to ensure long-term, normal performance.Ideally, the operating temperature should not exceed 85°C in order to ensure long-term performance.The mount is done using Surface Mount.UART is possible to ensure reliabilUARTy when the supply voltage is kept below 5.5V.When the supply voltage is kept above 2.97V, reliability can be ensured.In order for the device to operate efficiently, 5V is the supply voltage.

ST16C554DIQ64TR-F Features

4 serial I/Os
Operating supply voltage of 5V

ST16C554DIQ64TR-F Applications

There are a lot of Exar Corporation
ST16C554DIQ64TR-F UARTs applications.

Battery Operated Electronics
Handheld Terminal
Personal Digital Assistants
Cellular Phones DataPort
Wireless Infrared Data Communications Systems
Handheld Terminals and Tablets
Handheld Computers
Wireless Portable Point-of-Sale Terminals
GPS Devices
Personal Digital Assistants Modules
