Manufacturer No:

SN74LVC245AZQNR

Manufacturer:

TI

Package:

20-VFBGA

Description:

BOTTOM Transceiver, Non-Inverting 1.65V~3.6V 3-State Buffers 74LVC Series 74LVC245 20 Pins 24mA 24mA 20-VFBGA

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

SN74LVC245AZQNR information

TI SN74LVC245AZQNR technical specifications, attributes, parameters and parts with similar specifications to TI SN74LVC245AZQNR.

  • Type
  • Parameter
  • Lifecycle Status
  • LIFEBUY (Last Updated: 3 days ago)
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 20-VFBGA
  • Number of Pins
  • 20
  • Weight
  • 21.800783mg
  • Operating Temperature
  • -40°C~125°C TA
  • Packaging
  • Tape & Reel (TR)
  • Series
  • 74LVC
  • JESD-609 Code
  • e1
  • Pbfree Code
  • yes
  • Part Status
  • Last Time Buy
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 20
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Tin/Silver/Copper (Sn/Ag/Cu)
  • Additional Feature
  • WITH DIRECTION CONTROL
  • Subcategory
  • Bus Driver/Transceivers
  • Packing Method
  • TR
  • Technology
  • CMOS
  • Voltage - Supply
  • 1.65V~3.6V
  • Terminal Position
  • BOTTOM
  • Terminal Form
  • BALL
  • Peak Reflow Temperature (Cel)
  • 260
  • Supply Voltage
  • 1.8V
  • Terminal Pitch
  • 0.65mm
  • Base Part Number
  • 74LVC245
  • Pin Count
  • 20
  • Output Type
  • 3-State
  • Number of Elements
  • 1
  • Polarity
  • Non-Inverting
  • Supply Voltage-Max (Vsup)
  • 3.6V
  • Power Supplies
  • 3.3V
  • Number of Channels
  • 8
  • Load Capacitance
  • 50pF
  • Number of Ports
  • 2
  • Number of Bits
  • 8
  • Propagation Delay
  • 6.5 ns
  • Turn On Delay Time
  • 17 ns
  • Family
  • LVC/LCX/Z
  • Logic Function
  • Inverting, Transceiver
  • Direction
  • Bidirectional
  • Current - Output High, Low
  • 24mA 24mA
  • Logic Type
  • Transceiver, Non-Inverting
  • Max I(ol)
  • 0.024 A
  • Prop. Delay@Nom-Sup
  • 6.3 ns
  • Control Type
  • COMMON CONTROL

Download datasheets and manufacturer documentation for TI SN74LVC245AZQNR.

Datasheets:

PCN Obsolescence/ EOL:

SN74LVC245AZQNR Overview


There is a neat 20-VFBGA package used in buffer. A Tape & Reel (TR) external packaging is used for this buffer. The external packaging used in this logic IC is the Surface Mount external packaging. This is a typical Transceiver, Non-Inverting logic integrated circuit with a wide range of applications. There's a 1.65V~3.6V supply voltage for this logic IC. This automotive buffer is capable of working through -40°C~125°C TA. This buffer IC has a 24mA 24mA high and low logic state output current. There are 3-State outputs that digital buffer can handle. A total of 1 elements are used. 74LVC series devices are included in this network transceiver. 20 terminations with different functions are available on this transceiver. An input voltage of 1.8V is required. LVC/LCX/Z family part. With the electrical part, 20 pins are set. Surface Mount applications are suitable for it. There are 20 pins on digital buffer. The bus transceiver has 2 ports. For other related electronic components, you can search 74LVC245. In particular, automotive buffer is a type of Bus Driver/Transceivers. Power supplies with a 3.3V volt rating are recommended. The package is usually shaped like a TR. 8 efficient bits are included in the package of the network transceiver. For better service, buffer includes WITH DIRECTION CONTROL. High-quality communication is provided by 8 channels on thisnetwork transceiver. COMMON CONTROL control technology allows the logical driver to start up.

SN74LVC245AZQNR Features


Bus Driver/Transceivers
WITH DIRECTION CONTROL


SN74LVC245AZQNR Applications


There are a lot of Texas Instruments
SN74LVC245AZQNR Buffers & Transceivers applications.


  • Wireless modems
  • Remote controls
  • Wireless network systems
  • Satellite communications networks
  • Ethernet circuitry
  • Wired telephone
  • Cordless telephone
  • Desktop PC
  • Notebook
  • Pocket PC
