Manufacturer No:

SBRT4U45LP-7

Manufacturer:

DIODES

Package:

2-UDFN

Description:

Super Barrier Diode Rectifier Fast Recovery =< 500ns, > 200mA (Io) 520mV @ 4A -55°C~150°C 100?A @ 45V 2-Termination Tape & Reel (TR) 2-UDFN Surface Mount

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

SBRT4U45LP-7 information

DIODES SBRT4U45LP-7 technical specifications, attributes, parameters and parts with similar specifications to DIODES SBRT4U45LP-7.

  • Type
  • Parameter
  • Factory Lead Time
  • 22 Weeks
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 2-UDFN
  • Number of Pins
  • 2
  • Diode Element Material
  • SILICON
  • Packaging
  • Tape & Reel (TR)
  • Series
  • TrenchSBR
  • Published
  • 2015
  • JESD-609 Code
  • e3
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 2
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Matte Tin (Sn)
  • Additional Feature
  • FREE WHEELING DIODE, HIGH RELIABILITY
  • HTS Code
  • 8541.10.00.80
  • Technology
  • AVALANCHE
  • Terminal Position
  • BOTTOM
  • Terminal Form
  • NO LEAD
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Reference Standard
  • AEC-Q101
  • Number of Elements
  • 1
  • Speed
  • Fast Recovery =< 500ns, > 200mA (Io)
  • Diode Type
  • Super Barrier
  • Current - Reverse Leakage @ Vr
  • 100?A @ 45V
  • Voltage - Forward (Vf) (Max) @ If
  • 520mV @ 4A
  • Case Connection
  • CATHODE
  • Operating Temperature - Junction
  • -55°C~150°C
  • Output Current-Max
  • 4A
  • Application
  • EFFICIENCY
  • Voltage - DC Reverse (Vr) (Max)
  • 45V
  • Max Reverse Voltage (DC)
  • 45V
  • Average Rectified Current
  • 4A
  • Number of Phases
  • 1
  • Non-rep Pk Forward Current-Max
  • 45A
  • Reverse Current-Max
  • 100?A
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for DIODES SBRT4U45LP-7.

Environmental Information:

SBRT4U45LP-7 Overview


This device's average rectified current is zero volts.In the case of a maximum reverse current, the value reaches 100?A.In terms of output current, the maximum value is 4A.

SBRT4U45LP-7 Features


an average rectified current of 4A volts
A maximum reverse current of 100?A
4A is the maximum value


SBRT4U45LP-7 Applications


There are a lot of Diodes Incorporated
SBRT4U45LP-7 applications of single-phase diode rectifier.


  • DC motor control and drives
  • Battery chargers
  • Welders
  • Power converters
  • Reverse Polarity Protection
  • Ultra High-Speed Switching
  • Freewheeling
  • Polarity Protection Diode
  • Recirculating Diode
  • Switching Diode
