Renesas QS32390QG

Manufacturer No:

QS32390QG

Manufacturer:

Renesas

Package:

QSOP

Description:

28 Terminations 28 Pin Signal switch 8 Functions Min 4.75V V Max 5.25V V

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

QS32390QG information

Renesas QS32390QG technical specifications, attributes, parameters and parts with similar specifications to Renesas QS32390QG.

Type
Parameter

Factory Lead Time
7 Weeks

Mount
Surface Mount

Package / Case
QSOP

Number of Pins
28

Published
2005

JESD-609 Code
e3

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
28

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Subcategory
Other Logic ICs

Technology
CMOS

Terminal Position
DUAL

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Number of Functions
8

Supply Voltage
5V

Terminal Pitch
0.635mm

Pin Count
28

Operating Supply Voltage
5V

Temperature Grade
INDUSTRIAL

Max Supply Voltage
5.25V

Min Supply Voltage
4.75V

Power Dissipation
500mW

Propagation Delay
1.25 ns

Quiescent Current
3?A

Turn On Delay Time
7.5 ns

Family
32390

Logic Function
Demultiplexer, Multiplexer

Output Characteristics
3-STATE WITH SERIES RESISTOR

Supply Type
Single

Output Polarity
TRUE

High Level Output Current
-120mA

Low Level Output Current
120mA

Number of Input Lines
16

Independent Circuits
1

Number of Output Lines
8

Length
9.9mm

Width
3.8mm

Thickness
1.47mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Renesas QS32390QG.

QS32390QG Overview

The reason it is provided is that the board space can be saved by placing digital switch in the QSOP.The basic configuration of this system includes 28 terminations.The multiplexer's system is supplied with a voltage of 5V.Currently, this turn signal switch has a total of 28 component pins.A conductor terminates at GULL WING.Its supply type is Single, which is used as the source of power.Currently, it is configured with a 28 pin configuration.This unit is mounted in the way of Surface Mount.The logic switch object belongs to the family of 32390.It is provided that 5V has a power supply in order to function normally.In electronic terms, the digital switch ic is classified as part number Other Logic ICs.Without any external influences, it consumes 3?A current of multiplexer ic at all times.If the supply voltage is set to 5V, reliable performance of the multiplexers can be achieved.On the multiplexers, 16 input lines are provided for accepting voltage levels.Signal sources consist of output lines of 8.At 85°C, the maximum operating temperature of this signal switch is acceptable.It is recommended that a minimum operating temperature of the multiplexer of -40°C be maintained.In compliance with the applicable device specification, the signal switches has a maximum supply voltage of 5.25V.A minimum supply voltage of 4.75V is specified for the digital swith in accordance with its applicable specifications.

QS32390QG Features

Supplied in the QSOP package
Adopting a supply type of Single
Power supplies of 5V
Operating with the supply voltage of 5V
16 input lines
8 output lines

QS32390QG Applications

There are a lot of Integrated Device Technology (IDT)
QS32390QG Signal Switches / Multiplexers / Decoders applications.

Data collection system
Audio transmission
Video transmission
Image transmission
Recording transmission
Combinational circuit
Logic gates for other digital devices
Signal router
Data communication
Data bus control
