PIC24HJ12GP202-I/SO Information

Microchip PIC24HJ12GP202-I/SO technical specifications, attributes, parameters and parts with similar specifications to Microchip PIC24HJ12GP202-I/SO.

Type
Parameter

CPU Type
16-bit PIC MCU

CPU Speed Max MHz (megahertz)
40

Program Memory Size (KB)
12

Multiple Flash Panels
False

Direct Memory Access (DMA) Channels
0

Temp. Range Min.(C°)
-40

Temp. Range Max.(C°)
125

Operation Voltage Min.(V)
3

Operation Voltage Max.(V)
3.6

Pin Count
28

Type
Parameter

Low Power
No

Number of Comparators
0

ADC Modules
1

ADC Channels
10

ADC Resolution Max
12

ADC Sampling Rate (ksps)
500

Number of DACs
0

DAC outputs
0

Max DAC Resolution (bits)
0

Hardware RTCC
No

Download datasheets and manufacturer documentation for Microchip PIC24HJ12GP202-I/SO.

The PIC24H 16-bit device family employs a powerful 16-bit architecture, ideal for applications that rely on high-speed, repetitive computations, as well as control. The devices are pin compatible with the dsPIC33F family of devices, and share a very high degree of compatibility with the dsPIC30F family devices. This allows seamless migration options from/to PIC24F, dsPIC30F and dsPIC33F devices.

Up to 40 MIPS operation (3.0-3.6V)
Industrial temperature range (-40°C to +85°C)
Extended temperature range (-40°C to +125°C)

Modified Harvard architecture
C compiler optimized instruction set
16-bit-wide data path, 24-bit-wide instructions
Linear program memory addressing up to 4M instruction words
Linear data memory addressing up to 64 Kbytes
71 base instructions, mostly one word/one cycle
Sixteen 16-bit general purpose registers
Flexible and powerful addressing modes
16 x 16 multiply operations
32/16 and 16/16 divide operations
Up to ±16-bit shifts for up to 40-bit data

5-cycle latency
Up to 21 available interrupt sources
Up to three external interrupts
Seven programmable priority levels
Four processor exceptions

Peripheral Pin Select Functionality
Up to 21 programmable digital I/O pins
Wake-up/Interrupt-on-Change for up to 21 pins
Output pins can drive from 3.0V to 3.6V
Up to 5V output with open drain configurations on 5V tolerant pins
4 mA sink on all I/O pins

Flexible clock options: - External, crystal, resonator, internal RC, fully integrated Phase-Locked Loop (PLL) and extremely low-jitter PLL
Power-up Timer
Oscillator Start-up Timer/Stabilizer
Watchdog Timer with its own RC oscillator
Fail-Safe Clock Monitor (FSCM)
Reset by multiple sources

On-chip 2.5V voltage regulator
Switch between clock sources in real time
Idle, Sleep, and Doze modes with fast wake-up

Timer/Counters, up to three 16-bit timers: - Can pair up to make one 32-bit timer, one timer runs as Real-Time Clock with external 32.768 kHz oscillator and programmable prescaler
Input Capture (up to four channels): - Capture on up, down, or both edges, 16-bit capture input functions and 4-deep FIFO on each capture
Output Compare (up to two channels): - Single or Dual 16-bit Compare mode, 16-bit Glitchless PWM Mode

4-wire SPI with framing supports I/O interface to simple codecs, supports 8-bit and 16-bit data and all serial clock formats and sampling modes
I2C™ with Full Multi-Master Slave mode support, 7-bit and 10-bit addressing, bus collision detection and arbitration, integrated signal conditioning, slave address masking
UART with LIN bus support, IrDA® encoding and decoding in hardware, High-Speed Baud Mode, Hardware Flow Control with CTS and RTS

10-bit, 1.1 Msps or 12-bit, 500 Ksps conversion
Two and four simultaneous samples (10-bit ADC)
Up to 10 input channels with auto-scanning
Conversion start can be manual or synchronized with one of four trigger sources
Conversion possible in Sleep mode
±2 LSb max integral nonlinearity
±1 LSb max differential nonlinearity

18-pin PDIP/SOIC
28-pin SPDIP/SOIC/QFN/SSOP

PIC24HJ12GP202-I/SO Relevant information

PIC24HJ12GP202-I/SO FAQ

Can I request a quote for PIC24HJ12GP202-I/SO?

PIC24HJ12GP202-I/SO from Microchip is ready for RFQ submission. Send your target quantity and requirements, and AIChipLink will check current availability, lead time, and quantity-based pricing.

Why is pricing not shown as a fixed value for PIC24HJ12GP202-I/SO?

The final price for PIC24HJ12GP202-I/SO depends on requested quantity, supply conditions, date code, package option, and destination. An RFQ lets us return the current market quote for your order.

Which specifications should I review for PIC24HJ12GP202-I/SO?

PIC24HJ12GP202-I/SO is a Microchip Embedded part. Key details include Configurable Logic Cell Modules (CLC /CCL): 0 and Peripheral Pin Select (PPS)/Pin Muxing: Yes; contact us if you need the specifications verified before sourcing.

When will I receive a quotation for PIC24HJ12GP202-I/SO?

After you submit the RFQ for PIC24HJ12GP202-I/SO, our sales team typically replies within 24 hours with availability, unit pricing, lead time, shipping choices, and possible substitutes.

What is the expected shipping time for PIC24HJ12GP202-I/SO?

Once stock for PIC24HJ12GP202-I/SO is confirmed, available inventory can generally ship within 1–2 business days. The final schedule depends on quantity, warehouse source, and delivery address.

Can AIChipLink help find alternatives to PIC24HJ12GP202-I/SO?

Yes. If PIC24HJ12GP202-I/SO is unavailable, end-of-life, or outside your schedule, we can review comparable Microchip Embedded parts and compatible replacement options.

Microchip PIC24HJ12GP202-I/SO
