PHPT60603PYX Information

NEXPERIA PHPT60603PYX technical specifications, attributes, parameters and parts with similar specifications to NEXPERIA PHPT60603PYX.

  • Type
  • Parameter
  • Factory Lead Time
  • 8 Weeks
  • Contact Plating
  • Tin
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • SC-100, SOT-669
  • Number of Pins
  • 5
  • Transistor Element Material
  • SILICON
  • Collector-Emitter Breakdown Voltage
  • 60V
  • Number of Elements
  • 1
  • Operating Temperature
  • 175°C TJ
  • Type
  • Parameter
  • Packaging
  • Tape & Reel (TR)
  • Published
  • 2014
  • JESD-609 Code
  • e3
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 4
  • Max Power Dissipation
  • 25W
  • Terminal Position
  • SINGLE
  • Terminal Form
  • GULL WING
  • Peak Reflow Temperature (Cel)
  • 260

Download datasheets and manufacturer documentation for NEXPERIA PHPT60603PYX.

Datasheets:

PCN Packaging:

RohsStatement:

PHPT60603PYX Overview


This device has a DC current gain of 150 @ 500mA 2V, which is the ratio between the base current and the collector current.A VCE saturation (Max) of 225mV @ 50mA, 1A means Ic has reached its maximum value(saturated).Continuous collector voltages should be kept at -3A to achieve high efficiency.A high level of efficiency can be achieved if the base voltage of the emitter remains at 8V.As you can see, the part has a transition frequency of 110MHz.A breakdown input voltage of 60V volts can be used.A maximum collector current of 3A volts is possible.

PHPT60603PYX Features


the DC current gain for this device is 150 @ 500mA 2V
the vce saturation(Max) is 225mV @ 50mA, 1A
the emitter base voltage is kept at 8V
a transition frequency of 110MHz


PHPT60603PYX Applications


There are a lot of Nexperia USA Inc.
PHPT60603PYX applications of single BJT transistors.


  • Inverter
  • Interface
  • Driver
  • Muting
