NXP PCAL6524EVJ

Manufacturer No:

PCAL6524EVJ

Manufacturer:

NXP

Package:

36-VFBGA

Description:

I/O Expander 36-VFBGA

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

PCAL6524EVJ information

NXP PCAL6524EVJ technical specifications, attributes, parameters and parts with similar specifications to NXP PCAL6524EVJ.

Type
Parameter

Factory Lead Time
7 Weeks

Mounting Type
Surface Mount

Package / Case
36-VFBGA

Operating Temperature
-40°C~85°C

Packaging
Tape & Reel (TR)

Published
2010

Feature
POR

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Technology
CMOS

Voltage - Supply
1.65V~5.5V

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Output Type
Open Drain, Push-Pull

Interface
I2C

Number of I/O
24

Clock Frequency
1MHz

Interrupt Output
Yes

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for NXP PCAL6524EVJ.

Datasheets:

nxpusainc-pcal6524evj-datasheets-4521.pdf

Environmental Information:

nxpusainc-tef6657hnv102k-environmentalinformation-9391.pdf

PCAL6524EVJ Overview

24 I/Os are used in its programming.A 36-VFBGA is enclosed in the package with the device.In addition, it is available in a Tape & Reel (TR) case as well.The vote is delivered within 1.65V~5.5V.Mounting type Surface Mount is recommended.In operation, the device works when the temperature ranges between -40°C~85°C and X.As for the performance, it works with a frequency of 1MHz.To run NOT SPECIFIED, we utilize this part's peak reflow temperature.It is also possible to find POR with the use of this device.
