APEX PA107DP

Manufacturer No:

PA107DP

Manufacturer:

APEX

Package:

12-SIP

Description:

1.5A per Channel 300pA Instrumentational OP Amps ±20V~100V PA107 12 Pins 12-SIP

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

PA107DP information

APEX PA107DP technical specifications, attributes, parameters and parts with similar specifications to APEX PA107DP.

Type
Parameter

Factory Lead Time
26 Weeks

Mount
Through Hole

Mounting Type
Through Hole

Package / Case
12-SIP

Number of Pins
12

Operating Temperature
-25°C~85°C

Packaging
Tube

Series
Apex Precision Power®

Published
2012

JESD-609 Code
e3

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
12

ECCN Code
EAR99

Subcategory
Operational Amplifiers

Technology
HYBRID

Terminal Position
SINGLE

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Number of Functions
1

Supply Voltage
15V

Terminal Pitch
2.54mm

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Base Part Number
PA107

Qualification Status
Not Qualified

Number of Circuits
1

Operating Supply Current
30mA

Supply Current-Max
35mA

Slew Rate
3000V/μs

Architecture
VOLTAGE-FEEDBACK

Amplifier Type
Power

Current - Input Bias
300pA

Voltage - Supply, Single/Dual (±)
±20V~100V

Output Current per Channel
1.5A

Input Offset Voltage (Vos)
5mV

Gain Bandwidth Product
180MHz

Neg Supply Voltage-Nom (Vsup)
-15V

Unity Gain BW-Nom
180000 kHz

Low-Offset
NO

Frequency Compensation
YES AVCL>=20

Low-Bias
YES

Micropower
NO

Wideband
YES

Power
YES

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for APEX PA107DP.

Datasheets:

apexmicrotechnology-ek71-datasheets-0009.pdf

apexmicrotechnology-sa60-datasheets-3321.pdf

PA107DP Overview

Op amp is packaged in 12-SIP case. Op amps are Power types of amplifier on the chip. Instrumentation amplifier is delivered in a Tube case. The number of terminations approaches 12. Linear amplifier has a total of 12 pins. Please take in mind that op amp should be run at 15V. Instrumentation amplifier is a part of Operational Amplifiers. Linear amplifier includes 12 pins. Regarding input offset voltage, buffer amplifier rates 5mV voltage. Through Hole is the recommended mounting type of operational amplifiers. With regard to operating temperature, op amp ranges -25°C~85°C. Operational amplifier can operate supply current at 30mA. There are 1 circuits on op amps. Apex Precision Power® corresponds to linear amplifier's series.
