NXP NXH3670UK/A1Z

Manufacturer No:

NXH3670UK/A1Z

Manufacturer:

NXP

Package:

34-XFBGA, WLCSP

Description:

TxRx + MCU 2.36GHz~2.5GHz 1.14V~1.26V GPIO, I2S, SPI, UART 2Mbps 7mA - Receiving 10mA - Transmitting GFSK 96kB RAM 128kB ROM 34-XFBGA, WLCSP

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

NXH3670UK/A1Z information

NXP NXH3670UK/A1Z technical specifications, attributes, parameters and parts with similar specifications to NXP NXH3670UK/A1Z.

Type
Parameter

Factory Lead Time
20 Weeks

Package / Case
34-XFBGA, WLCSP

Operating Temperature
-20°C~85°C TA

Packaging
Tape & Reel (TR)

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Type
TxRx + MCU

Voltage - Supply
1.14V~1.26V

Frequency
2.36GHz~2.5GHz

Memory Size
96kB RAM 128kB ROM

Protocol
Bluetooth v4.1

Power - Output
4dBm

RF Family/Standard
Bluetooth

Sensitivity
-94dBm

Data Rate (Max)
2Mbps

Serial Interfaces
GPIO, I2S, SPI, UART

Current - Receiving
7mA

Current - Transmitting
10mA

Modulation
GFSK

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for NXP NXH3670UK/A1Z.

Datasheets:

nxpusainc-nxh3670uka1z-datasheets-3497.pdf

nxpusainc-nxh3670uka1z-datasheets-3498.pdf

Environmental Information:

nxpusainc-tef6657hnv102k-environmentalinformation-9391.pdf

NXH3670UK/A1Z Overview

To save board space, RF transceiver IC uses the 34-XFBGA, WLCSP package. In this case, it emerges as a TxRx + MCU with transceiver RF's a high efficiency.The transceiver RF' packaging Tape & Reel (TR) provides high reliability.The frequency of 2.36GHz~2.5GHz determines how RF transceiver operates .

NXH3670UK/A1Z Features

34-XFBGA, WLCSP package
TxRx + MCU
Tape & Reel (TR) is used

NXH3670UK/A1Z Applications

There are a lot of NXP USA Inc.
NXH3670UK/A1Z RF Transceiver ICs applications.

Internet Radio
Industrial Controls
Chemical Sensors
Security Systems
M2M Communication
Remote Device Management
Low-power IoT applications
LoT applications
Power Amplifier (PA)
Low Noise Amplifier (LNA)
