Manufacturer No:

NX3DV3899HR,115

Manufacturer:

NXP

Package:

16-XFQFN Exposed Pad

Description:

40ns, 20ns DPDT 3.3Ohm QUAD Analog Switches BREAK-BEFORE-MAKE NX3DV3899 16 Pins 5nA 16-XFQFN Exposed Pad

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

NX3DV3899HR,115 information

NXP NX3DV3899HR,115 technical specifications, attributes, parameters and parts with similar specifications to NXP NX3DV3899HR,115.

  • Type
  • Parameter
  • Factory Lead Time
  • 7 Weeks
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 16-XFQFN Exposed Pad
  • Surface Mount
  • YES
  • Operating Temperature
  • -40°C~125°C TA
  • Packaging
  • Tape & Reel (TR)
  • Published
  • 2011
  • JESD-609 Code
  • e3
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 16
  • Terminal Finish
  • Matte Tin (Sn)
  • Subcategory
  • Multiplexer or Switches
  • Terminal Position
  • QUAD
  • Terminal Form
  • NO LEAD
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Number of Functions
  • 2
  • Terminal Pitch
  • 0.5mm
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Base Part Number
  • NX3DV3899
  • Output
  • SEPARATE OUTPUT
  • Pin Count
  • 16
  • JESD-30 Code
  • S-PQCC-N16
  • Qualification Status
  • Not Qualified
  • Number of Circuits
  • 2
  • -3db Bandwidth
  • 200MHz
  • On-State Resistance (Max)
  • 3.3Ohm
  • Multiplexer/Demultiplexer Circuit
  • 2:2
  • Current - Leakage (IS(off)) (Max)
  • 5nA
  • Channel Capacitance (CS(off), CD(off))
  • 8pF
  • Switch Circuit
  • DPDT
  • Switch Time (Ton, Toff) (Max)
  • 40ns, 20ns
  • Charge Injection
  • 4pC
  • Channel-to-Channel Matching (?Ron)
  • 700m ?
  • Crosstalk
  • -90dB @ 1MHz
  • Switching
  • BREAK-BEFORE-MAKE
  • Switch-on Time-Max
  • 90ns
  • Voltage - Supply, Single (V+)
  • 1.4V~4.3V
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for NXP NX3DV3899HR,115.

Datasheets:

Environmental Information:

PCN Packaging:

NX3DV3899HR,115 Overview


The electronic part can be shipped overseas conveniently because it is packaged in 16-XFQFN Exposed Pad. In order to provide high reliability, an advanced packaging method Tape & Reel (TR) is used. There is an analog multiplexer mounted in position Surface Mount. There is 2:2 ratio between the number of multiplexers and demultiplexers. Around -40°C~125°C TA is the extended operating temperature. In total, there are 16 terminations. There are 16 pins injected into the electronic part body. The analog switch ics are built using DPDT switching circuits. A total of 2 circuits make up this switch device. Search with NX3DV3899 if you are looking for analog multiplexer variants. There is a standard Multiplexer or Switches analogue multiplexer here. A voltage of 1.4V~4.3V is required to drain this analog switch from a single voltage supply. There are SEPARATE OUTPUT outputs on this analog switch ic.

NX3DV3899HR,115 Features


Switch Circuit: DPDT
-3db Bandwidth: 200MHz


NX3DV3899HR,115 Applications


There are a lot of NXP USA Inc.
NX3DV3899HR,115 Analog Switches & Multiplexers ICs applications.


  • Isolation
  • Medical
  • Imaging
  • Ultrasound
  • Audio and video switching
  • Automatic test equipment
  • Precision data acquisition
  • Battery-powered systems
