Manufacturer No:

NID6002NT4

Manufacturer:

ONSEMI

Package:

TO-252-3, DPak (2 Leads + Tab), SC-63

Description:

N-Channel PMIC HDPlus? Series NID6002N 3 Pin TO-252-3, DPak (2 Leads + Tab), SC-63

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

NID6002NT4 information

ONSEMI NID6002NT4 technical specifications, attributes, parameters and parts with similar specifications to ONSEMI NID6002NT4.

  • Type
  • Parameter
  • Lifecycle Status
  • OBSOLETE (Last Updated: 2 weeks ago)
  • Mounting Type
  • Surface Mount
  • Package / Case
  • TO-252-3, DPak (2 Leads + Tab), SC-63
  • Number of Pins
  • 3
  • Operating Temperature
  • -55°C~150°C TJ
  • Packaging
  • Tape & Reel (TR)
  • Series
  • HDPlus?
  • Published
  • 2007
  • JESD-609 Code
  • e0
  • Feature
  • Auto Restart, Slew Rate Controlled
  • Pbfree Code
  • no
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Tin/Lead (Sn/Pb)
  • Voltage - Rated DC
  • 65V
  • Reach Compliance Code
  • not_compliant
  • Current Rating
  • 6.5A
  • Base Part Number
  • NID6002N
  • Pin Count
  • 3
  • Number of Outputs
  • 1
  • Output Type
  • N-Channel
  • Max Output Current
  • 6.5A
  • Interface
  • On/Off
  • Output Configuration
  • Low Side
  • Power Dissipation
  • 2.5W
  • Voltage - Supply (Vcc/Vdd)
  • Not Required
  • Input Type
  • Non-Inverting
  • Switch Type
  • General Purpose
  • Rise Time
  • 250ns
  • Fall Time (Typ)
  • 660 ns
  • Turn-Off Delay Time
  • 840 ns
  • Continuous Drain Current (ID)
  • 6.5A
  • Ratio - Input:Output
  • 1:1
  • Gate to Source Voltage (Vgs)
  • 14V
  • Voltage - Load
  • 60V Max
  • Fault Protection
  • Current Limiting (Fixed), Over Temperature, Over Voltage
  • Drain to Source Breakdown Voltage
  • 70V
  • Rds On (Typ)
  • 185m ?
  • Drain to Source Resistance
  • 210mOhm
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Contains Lead

Download datasheets and manufacturer documentation for ONSEMI NID6002NT4.

Datasheets:

PCN Obsolescence/ EOL:

ReachStatement:

NID6002NT4 Overview


Tape & Reel (TR) is the way it's packaged.Package TO-252-3, DPak (2 Leads + Tab), SC-63 contains it.The lighting driver has the mounting type Surface Mount.It owns the General Purpose switch type.Keeping the temperature at -55°C~150°C TJ ensures reliable operation.The LED driver has 1 outputs.Operation is based on Not Required supply voltage.Voltage output is N-Channel volts at maximum.Features of the lighting driver are Auto Restart, Slew Rate Controlled.The NID6002N family contains this object.For operation, we use the 3 pins.Maximum output current falls to 6.5A when operation criteria are met.In total, it has 3 pins.This electrical component can be found in the HDPlus? series.
