NC7WZ14P6X Information

ONSEMI NC7WZ14P6X technical specifications, attributes, parameters and parts with similar specifications to ONSEMI NC7WZ14P6X.

  • Type
  • Parameter
  • Type
  • Inverter
  • VCC Min (V)
  • 1.65
  • Package Type
  • SC-88-6 / SC-70-6 / SOT-363-6
  • Case Outline
  • 419B-02
  • MSL Type
  • 1
  • MSL Temp (°C)
  • 260
  • Container Type
  • REEL
  • Container Qty.
  • 3000
  • Channels
  • 2
  • VCC Max (V)
  • 5.5
  • Type
  • Parameter
  • tpd Max (ns)
  • 4
  • IO Max (mA)
  • 32

Download datasheets and manufacturer documentation for ONSEMI NC7WZ14P6X.

Datasheet:

Package Drawing:

The NC7WZ14 is a dual inverter with Schmitt trigger input from onsemi's Ultra-High Speed (UHS) Series of TinyLogic® in the space saving SC70 6-lead package. The device is fabricated with advanced CMOS technology to achieve ultra-high speed with high output drive while maintaining low static power dissipation over a very broad VCC operating range. The device is specified to operate over the 1.65V to 5.5V VCC range. The inputs and outputs are high-impedance when VCC is 0V. Inputs tolerate voltages up to 7V independent of VCC operating voltage. Schmitt trigger inputs achieve typically 1V hysteresis between the positive-and negative-going input threshold voltage at 5V.

Application

  • This product is general usage and suitable for many different applications.

Feature

  • Ultra-High Speed: tPD 3.2ns (Typical) into 50pF at 5V VCC
  • High Output Drive: ±24mA at 3V VCC
  • Broad VCC Operating Range: 1.65V to 5.5V
  • Matches Performance of LCX when Operated at 3.3V VCC
  • Power Down High Impedance Inputs/Outputs
  • Over-Voltage Tolerance Inputs Facilitate 5V to 3V Translation
  • Proprietary Noise/EMI Reduction Circuitry
  • Ultra-Small MicroPak™ Packages
  • Space-Saving SC70 Package
