NXP MPX2050DP

Manufacturer No:

MPX2050DP

Manufacturer:

NXP

Package:

4-SIP Module

Description:

MPX2050 Series Differential Pressure Sensor Wheatstone Bridge -40°C~125°C 7.25PSI (50kPa) Barbed 0 mV ~ 40 mV (10V) 10V~16V Temperature Compensated

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MPX2050DP information

NXP MPX2050DP technical specifications, attributes, parameters and parts with similar specifications to NXP MPX2050DP.

Type
Parameter

Factory Lead Time
12 Weeks

Package / Case
4-SIP Module

Surface Mount
NO

Mounting Feature
THROUGH HOLE MOUNT

Operating Temperature
-40°C~125°C

Series
MPX2050

Published
2004

Feature
Temperature Compensated

Part Status
Active

Moisture Sensitivity Level (MSL)
Not Applicable

ECCN Code
EAR99

Applications
Board Mount

HTS Code
8542.39.00.01

Voltage - Supply
10V~16V

Output
0 mV ~ 40 mV (10V)

Termination Style
PC Pin

Body Length or Diameter
29.46mm

Body Breadth
10.67 mm

Output Type
Wheatstone Bridge

Response Time
1000 µs

Operating Pressure
7.25PSI (50kPa)

Pressure Type
Differential

Port Style
Barbed

Port Size
Male - 0.19 4.93mm Tube Dual

Maximum Pressure
29.01PSI (200kPa)

Sensors/Transducers Type
PRESSURE SENSOR,PEIZORESISTIVE

Housing
PLASTIC

Pressure Range-Max
7.25 Psi

Accuracy-Max
0.25%

Offset-Nom
0MV

Sensitivity (mV/V)
0.8 mV/V

Body Height
17.78mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for NXP MPX2050DP.

MPX2050DP Overview

For convenience, this transducer is included in the 4-SIP Module package. The temperature of the transducers should be set to -40°C~125°C to ensure reliable performance. The transducers can operate well with a supply voltage of 10V~16V. The maximum pressure range set by this transducer is 7.25 Psi.

MPX2050DP Features

Moisture Sensitivity Level: Not Applicable
Package / Case: 4-SIP Module
Operating Temperature: -40°C~125°C
MPX2050 series
Sensitivity (mV/V): 0.8 mV/V
Operating Pressure: 7.25PSI (50kPa)

MPX2050DP Applications

There are a lot of NXP USA Inc.
MPX2050DP Transducers applications.

General Purpose
Process Control
Altitude Control of Drones and Flying Toys
Mobile Phones
Virtual Reality and Gaming Equipment
Indoor/Outdoor Navigation (dead-reckoning, floor/elevator/step detection)
Vertical velocity monitoring
Leisure, Sports, and Fitness Activity Identification
Weather Forecasting
Hydrogen Storage
