APEX MP111FD

Manufacturer No:

MP111FD

Manufacturer:

APEX

Package:

34-DIP Module

Description:

15A per Channel 100pA 92 dB Instrumentational OP Amps 30V~100V ±15V~50V MP*FD 34 Pins 34-DIP Module

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MP111FD information

APEX MP111FD technical specifications, attributes, parameters and parts with similar specifications to APEX MP111FD.

Type
Parameter

Factory Lead Time
8 Weeks

Mount
Through Hole

Mounting Type
Through Hole

Package / Case
34-DIP Module

Operating Temperature
-40°C~85°C

Packaging
Bulk

Series
Apex Precision Power®

Published
2012

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
34

ECCN Code
EAR99

Subcategory
Operational Amplifier

Technology
HYBRID

Terminal Position
DUAL

Terminal Form
PIN/PEG

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Number of Functions
1

Supply Voltage
45V

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Base Part Number
MP*FD

Pin Count
34

JESD-30 Code
R-XDMA-P34

Qualification Status
Not Qualified

Operating Supply Current
142mA

Slew Rate
130V/μs

Amplifier Type
Power

Common Mode Rejection Ratio
92 dB

Current - Input Bias
100pA

Voltage - Supply, Single/Dual (±)
30V~100V ±15V~50V

Output Current per Channel
15A

Input Offset Voltage (Vos)
1mV

Gain Bandwidth Product
6MHz

Neg Supply Voltage-Nom (Vsup)
-45V

Unity Gain BW-Nom
6000 kHz

Supply Voltage Limit-Max
50V

Neg Supply Voltage-Max (Vsup)
-50V

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for APEX MP111FD.

Datasheets:

apexmicrotechnology-ek57-datasheets-0101.pdf

MP111FD Overview

In order to protect the op amps, a 34-DIP Module case is used. There are two types of operational amplifiers in this circuit. In the case of Bulk cases, linear amplifier will be delivered. In recent months, the number of terminations has approached 34. It consists of a total of 34 pins in total. It would be helpful if you could remember that this op amp ic should be powered by an 45V battery. A type of Operational Amplifier buffer op amp is what this device is specifically, to be more precise. In terms of input offset voltage, operational amplifier rates 1mV. This electronic component is recommended to be mounted using the mounting type Through Hole. It is recommended that this op amp ic be operated at a temperature no higher than -40°C~85°C for optimal performance. In order for this instrumentation amplifier to operate, the supply current needs to be between 142mA and 10 . In total, there are 1 circuits on this buffer amplifier. Apex Precision Power® is the number that corresponds to the series of the buffer op amp.
