Microchip MCP4921-E/P

Manufacturer No:

MCP4921-E/P

Manufacturer:

Microchip

Package:

8-DIP (0.300, 7.62mm)

Description:

Single-channel, 12-bit voltage output DAC with SPI interface and external Vref. AEC-Q100 qualified.

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MCP4921-E/P information

Microchip MCP4921-E/P technical specifications, attributes, parameters and parts with similar specifications to Microchip MCP4921-E/P.

Type
Parameter

Resolution
12

Number of Input Channels
1

Interface
SPI

INL Max LSB
12

Output Settling Time (μs)
4.5

Memory Type
None

Download datasheets and manufacturer documentation for Microchip MCP4921-E/P.

MCP4921 is a single channel, 12-bit DAC with an external voltage reference pin and SPI interface. It offers high accuracy and low power consumption and is available in various packages. This device is a part of the MCP4901/MCP4911/MCP4921 product family, which are single channel 8-bit/10-bit/12-bit DACs which use an external voltage reference (VREF). These devices provide very high accuracy and low noise performance, and are suitable for consumer and industrial applications, such as set point control, offset adjustment and sensor calibration applications. The low power consumption and small package options make these devices very attractive for many portable and battery-powered applications. If two outputs are needed then the MCP4902/4912/4922 dual channel product family can be used.

We welcome questions, comments and recommendations for improvements to this page - please contact us at: DACwebrequests@microchip.com if you have any; please mention the part number in the email subject header.

12-bit Resolution
Single Channel Voltage Output
2.7V to 5.5V Operation
Operating Current 175µA (typ)
External Voltage Reference Pin
INL ±2 LSB (typ)
DNL ±0.75 LSB (max)
Output Settling Time 4.5 µs
SPI Interface
8-pin PDIP, SOIC, MSOP and 2x3 DFN packages
Temperature Range -40°C to +125°C
AEC-Q100 Grade 1 qualified

User Guide
