ONSEMI MC74HC244ADTG

Manufacturer No:

MC74HC244ADTG

Manufacturer:

ONSEMI

Package:

20-TSSOP (0.173, 4.40mm Width)

Description:

Octal 3-State Non-Inverting Buffer/Line Driver/Line Receiver

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MC74HC244ADTG information

ONSEMI MC74HC244ADTG technical specifications, attributes, parameters and parts with similar specifications to ONSEMI MC74HC244ADTG.

Type
Parameter

Channels
8

Case Outline
9.48

MSL Type
1

Container Type
TUBE

Container Qty.
75

VCC Max (V)
6

tpd Max (ns)
22

IO Max (mA)
6

Package Type
TSSOP-20

MSL Temp (°C)
260

Output
3-State

VCC Min (V)
2

Download datasheets and manufacturer documentation for ONSEMI MC74HC244ADTG.

Datasheet:

mc74hc244a-d.pdf

Package Drawing:

06526ff4116014df831138886d10ba14.pdf

0c98c871938c17f8163c58ec9759307e.pdf

High-Performance Silicon-Gate CMOS The MC74HC244A is identical in pinout to the LS244. The device inputs are compatible with standard CMOS outputs; with pullup resistors, they are compatible with LSTTL outputs. This octal noninverting buffer/line driver/line receiver is designed to be used with 3-state memory address drivers, clock drivers, and other bus-oriented systems. The device has noninverting outputs and two active-low output enables. The HC244A is similar in function to the HC240A and HC241A.

Application

This product is general usage and suitable for many different applications.

End Product

*Standard Device (No Specific End Product)

Feature

Output Drive Capability: 15 LSTTL Loads
Operating Voltage Range: 2 to 6 V
Outputs Directly Interface to CMOS, NMOS, and TTL
Low Input Current: 1 mA
High Noise Immunity Characteristic of CMOS Devices
In Compliance with the Requirements Defined by JEDEC Standard No. 7A
Chip Complexity: 136 FETs or 34 Equivalent Gates
Pb-Free Packages are Available*
