ONSEMI MC33202P

Manufacturer No:

MC33202P

Manufacturer:

ONSEMI

Package:

PDIP

Description:

200nA 60 dB Instrumentational OP Amps 6V 8 Pins PDIP

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MC33202P information

ONSEMI MC33202P technical specifications, attributes, parameters and parts with similar specifications to ONSEMI MC33202P.

Type
Parameter

Lifecycle Status
OBSOLETE (Last Updated: 1 day ago)

Package / Case
PDIP

Surface Mount
NO

Number of Pins
8

Packaging
Rail/Tube

Published
2004

JESD-609 Code
e0

Pbfree Code
no

Part Status
Discontinued

Number of Terminations
8

ECCN Code
EAR99

Max Operating Temperature
105°C

Min Operating Temperature
-40°C

Subcategory
Operational Amplifier

Technology
BIPOLAR

Terminal Position
DUAL

Terminal Form
THROUGH-HOLE

Peak Reflow Temperature (Cel)
240

Number of Functions
2

Supply Voltage
5V

Time@Peak Reflow Temperature-Max (s)
30

Pin Count
8

Operating Supply Voltage
6V

Number of Elements
2

Temperature Grade
INDUSTRIAL

Max Supply Voltage
12V

Min Supply Voltage
1.8V

Nominal Supply Current
1.8mA

Current - Output
80mA

Slew Rate
1 V/μs

Architecture
VOLTAGE-FEEDBACK

Amplifier Type
OPERATIONAL AMPLIFIER

Common Mode Rejection Ratio
60 dB

Current - Input Bias
200nA

Input Offset Voltage (Vos)
8mV

Gain Bandwidth Product
2.2MHz

Unity Gain BW-Nom
2200 kHz

Voltage Gain
109.54dB

Power Supply Rejection Ratio (PSRR)
66.02dB

Low-Offset
NO

Frequency Compensation
YES

Max Dual Supply Voltage
6V

Min Dual Supply Voltage
900mV

Nominal Gain Bandwidth Product
2.2MHz

Height Seated (Max)
5.33mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for ONSEMI MC33202P.

ReachStatement:

onsemiconductor-6svp22m-reachstatement-6839.pdf

Datasheets:

onsemiconductor-mc33202p-datasheets-0083.pdf

MC33202P Overview

In order to protect the op amps, a PDIP case is used. There are two types of operational amplifiers in this circuit. In the case of Rail/Tube cases, linear amplifier will be delivered. In recent months, the number of terminations has approached 8. It consists of a total of 8 pins in total. It would be helpful if you could remember that this op amp ic should be powered by an 5V battery. A type of Operational Amplifier buffer op amp is what this device is specifically, to be more precise. It has 8 pins that make up the linear amplifier. In terms of input offset voltage, operational amplifier rates 8mV. Maintain 109.54dB as the voltage gain. It is recommended that the temperature of this op amp ic should not fall below -40°C degrees Fahrenheit at any time. Linear amplifier shouldn't be used above 105°C degrees. As a whole, there are 2 elements that make up this buffer amplifier. The operating supply voltage of the buffer op amp is rated at 6V. When it comes to the voltage from which this electrical part will operate, it can operate at a maximum of less than 12V. It is recommended that you keep the instrumentation amplifier's supply voltage higher than 1.8V when using it. It is recommended that you conduct this electronic part using the dual supply voltage of 6V.

MC33202P Features

8 Pins
supply voltage of 5V
109.54dB voltage gain

MC33202P Applications

There are a lot of ON Semiconductor
MC33202P Instrumentational OP Amps applications.

Differentiator circuits
Logarithmic operation circuits
Exponential operation circuits
Multiplication circuits
Division circuits
Precision measurement
Power control
Information processing
Weak signal detection
Signal amplification
