ADI MAX17244ETERA+

Manufacturer No:

MAX17244ETERA+

Manufacturer:

ADI

Package:

16-WFQFN Exposed Pad

Description:

16 Terminals 3.5V MAX17244 DC DC Voltage Regulator SWITCHING REGULATOR 1 Outputs 400kHz~2.2MHz Tube 2.5A 16-WFQFN Exposed Pad

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MAX17244ETERA+ information

ADI MAX17244ETERA+ technical specifications, attributes, parameters and parts with similar specifications to ADI MAX17244ETERA+.

Type
Parameter

Factory Lead Time
6 Weeks

Mounting Type
Surface Mount

Package / Case
16-WFQFN Exposed Pad

Surface Mount
YES

Operating Temperature
-40°C~85°C TA

Packaging
Tube

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
16

ECCN Code
EAR99

Additional Feature
ALSO OPERATES IN PFM CONTROL TECHNIQUE; ALSO AVAILABLE VOUT=5V

Technology
BICMOS

Terminal Position
QUAD

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Terminal Pitch
0.8mm

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Base Part Number
MAX17244

Function
Step-Down

Number of Outputs
1

Voltage - Input (Max)
36V

Output Voltage
3.3V

Output Type
Programmable (Fixed)

Voltage - Input (Min)
3.5V

Analog IC - Other Type
SWITCHING REGULATOR

Output Configuration
Positive

Current - Output
2.5A

Voltage - Output (Min/Fixed)
1V 3.3V

Topology
Buck

Control Mode
CURRENT-MODE

Frequency - Switching
400kHz~2.2MHz

Control Technique
PULSE WIDTH MODULATION

Synchronous Rectifier
Yes

Voltage - Output (Max)
10V

Length
5mm

Height Seated (Max)
0.8mm

Width
5mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for ADI MAX17244ETERA+.

Datasheets:

maximintegrated-max17244eterbt-datasheets-1460.pdf

MAX17244ETERA+ Overview

This harley voltage regulator utilizes the Tube package for optimized performance. There are 16 terminations in this voltage regulator. The type of analog IC that this voltage regulator is equipped with is SWITCHING REGULATOR. This harley voltage regulator is available in the 16-WFQFN Exposed Pad package for the purpose of space saving. DC DC switching regulator is configured with 1 outputs. This DC DC switching regulator generates Programmable (Fixed) output on its output pins. This voltage regulator 12v fits the Surface Mount mounting. When operating, adjusting voltage regulator's operating temperature should be kept at -40°C~85°C TA. The switching frequency of this DC-DC switching regulator reaches 400kHz~2.2MHz. This voltage regulator is able to operate with the minimal input voltage of 3.5V. DC DC switching regulator's output voltage (Min/Fixed) amounts to 1V 3.3V. The output current of 2.5A makes dc to dc voltage regulator feature maximum design flexibility. Voltage regulator has an input voltage (Max) of 36V. The peak reflow temperature of this regulator amounts to NOT SPECIFIED to be essentially indestructible. Voltage regulator is designed to provide a nominal input voltage of 14V to meet the operation requirements. This DC/DC regulator belongs to the MAX17244 family. The adjusting voltage regulator's output voltage is maintain at 3.3V. DC DC switching regulator is able to operate in an easy way on the basis of the maximal output voltage of 10V. The ALSO OPERATES IN PFM CONTROL TECHNIQUE; ALSO AVAILABLE VOUT=5V feature adds to the efficiency and stability of this switching regulator.
