ST STBCFG01JR

Manufacturer No:

STBCFG01JR

Manufacturer:

Package:

25-UFBGA, FCBGA

Description:

STBCFG01 25-UFBGA, FCBGA Tape & Reel (TR) 5V 1.2A 25 Terminals

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

STBCFG01JR information

ST STBCFG01JR technical specifications, attributes, parameters and parts with similar specifications to ST STBCFG01JR.

Type
Parameter

Lifecycle Status
NRND (Last Updated: 7 months ago)

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
25-UFBGA, FCBGA

Number of Pins
25

Packaging
Tape & Reel (TR)

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
25

ECCN Code
EAR99

Max Operating Temperature
85°C

Min Operating Temperature
-30°C

Terminal Position
BOTTOM

Terminal Form
BALL

Number of Functions
1

Supply Voltage
5V

Terminal Pitch
0.4mm

Base Part Number
STBCFG01

Output Voltage
5V

Operating Supply Voltage
5V

Temperature Grade
OTHER

Supply Voltage-Min (Vsup)
3.78V

Number of Channels
2

Interface
I2C

Output Current
1.2A

Adjustable Threshold
YES

Fault Protection
Over Current, Over Voltage

Battery Chemistry
Lithium-Ion

Number of Cells
1

Length
2.28mm

Height Seated (Max)
0.605mm

REACH SVHC
No SVHC

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for ST STBCFG01JR.

Datasheets:

stmicroelectronics-stbcfg01jr-datasheets-6688.pdf

STBCFG01JR Overview

There is an Tape & Reel (TR) package that contains it. The 25-UFBGA, FCBGA package includes it as a convenience.Mounting type is Surface Mount.It uses an analog integrated circuit of type POWER SUPPLY MANAGEMENT CIRCUIT.Parts related to the base part number STBCFG01 can be found based on that number.It contains 25 terminations.It operates on the basis of 25 pins.A total of 2 channels are available.Battery voltage should be 5V.High efficiency can be achieved with a 5V output voltage.There is 1.2A output current when the device operates.As far as the mounting is concerned, it is mounted in the way of Surface Mount.It is recommended that the supply voltage be set to 5V for maximum efficiency.In order to ensure normal operation, the supply voltage (Vsup) should be kept above 3.78V.A minimum working temperature of -30°C degrees Celsius is required for reliable operation.Operating temperatures up to 85°C°C allow for reliable operation.

STBCFG01JR Features

2 channels
25-UFBGA, FCBGA package

STBCFG01JR Applications

There are a lot of STMicroelectronics
STBCFG01JR Battery Chargers ICs applications.

Fast charge
Fleet management
Shop charger
Golf carts
Forklift
Pallet jacks
Personnel carriers
Maintenance shops
Rental fleets
Truck dealers
