Renesas M3823AGFFP#U0

Manufacturer No:

M3823AGFFP#U0

Manufacturer:

Renesas

Package:

80-BQFP

Description:

60KB 60K x 8 QzROM 740 8-Bit Microcontroller 740/38000 Series M3823 80 Pin 10MHz 80-BQFP

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

M3823AGFFP#U0 information

Renesas M3823AGFFP#U0 technical specifications, attributes, parameters and parts with similar specifications to Renesas M3823AGFFP#U0.

Type
Parameter

Factory Lead Time
24 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
80-BQFP

Number of Pins
80

Operating Temperature
-20°C~85°C TA

Packaging
Tray

Series
740/38000

Published
2007

Pbfree Code
yes

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Max Power Dissipation
300mW

Technology
CMOS

Frequency
10MHz

Base Part Number
M3823

Pin Count
80

Operating Supply Voltage
5V

Interface
UART, USART

Memory Size
60kB

Oscillator Type
Internal

Number of I/O
49

RAM Size
2.5K x 8

Memory Type
QzROM, ROM

uPs/uCs/Peripheral ICs Type
MICROCONTROLLER

Core Processor
740

Peripherals
LCD, WDT

Program Memory Type
QzROM

Core Size
8-Bit

Program Memory Size
60KB 60K x 8

Connectivity
SIO, UART/USART

Data Converter
A/D 8x8b, 8x10b

Access Time
10 μs

Data Bus Width
8b

Number of Timers/Counters
5

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Renesas M3823AGFFP#U0.

ConflictMineralStatement:

nec-dn1c100m1s-conflictmineralstatement-8243.pdf

M3823AGFFP#U0 Overview

A 80-BQFP package is included. In total, it has 49 inputs and outputs. This Microcontroller is mounted using the Surface Mount mounting type. Powered by the 8-Bit core, it offers a wide range of capabilities. The type of memory that the program uses is QzROM. The temperature range of this Microcontroller is within the range of -20°C~85°C TA. 740/38000 series components belong to this electrical component. Its program memory size is 60KB 60K x 8. There is a 740 Core Processor inside MCU that provides this device with its power. MICROCONTROLLER uPs, uCs, and peripheral ICs make up the Microcontroller. 60kB memory size belongs to the part. M3823 is the base part number that you can use to find alternatives. A good performance can be achieved at a frequency of 10MHz, as long as it is operated at a low power consumption. On the chip, there are 80 pins that are accessible. A total of 5 timers/counters are included in the package. A total of 80 pins are present. There's built-in QzROM, ROM memory in the equipment.
