Harwin M22-5330505
Harwin M22-5330505

Harwin M22-5330505

Manufacturer No:

M22-5330505

Manufacturer:

Harwin

Package:

SIL

Description:

M22 Series 1-Row Header, Cuttable Solder Brass Bulk Surface Mount, Right Angle Gold Polyamide (PA6T), Nylon 6T 5-Position Board to Board or Cable 0.079 2.00mm Height

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

M22-5330505 information

Harwin M22-5330505 technical specifications, attributes, parameters and parts with similar specifications to Harwin M22-5330505.

  • Type
  • Parameter
  • Factory Lead Time
  • 13 Weeks
  • Contact Material
  • Brass
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount, Right Angle
  • Package / Case
  • SIL
  • Contact Shape
  • Square
  • Insulation Material
  • Polyamide (PA6T), Nylon 6T
  • Operating Temperature
  • -40°C~105°C
  • Packaging
  • Bulk
  • Series
  • M22
  • Published
  • 2011
  • JESD-609 Code
  • e4
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Solder
  • Connector Type
  • Header, Cuttable
  • Number of Positions
  • 5
  • Number of Rows
  • 1
  • Gender
  • Male
  • Additional Feature
  • ROHS COMPLIANT
  • Fastening Type
  • Push-Pull
  • Subcategory
  • Headers and Edge Type Connectors
  • Contact Finish - Mating
  • Gold
  • DIN Conformance
  • NO
  • IEC Conformance
  • NO
  • Filter Feature
  • NO
  • Contact Type
  • Male Pin
  • Mixed Contacts
  • NO
  • Option
  • GENERAL PURPOSE
  • Current Rating (Amps)
  • 2A per Contact
  • Total Number of Contacts
  • 5
  • Insulation Height
  • 0.079 2.00mm
  • Style
  • Board to Board or Cable
  • Number of Positions Loaded
  • All
  • Current Rating
  • 1A
  • Pitch - Mating
  • 0.079 2.00mm
  • Insulation Color
  • Black
  • Number of Conductors
  • ONE
  • Reference Standard
  • UL
  • Reliability
  • COMMERCIAL
  • Body Length or Diameter
  • 0.394 inch
  • Shrouding
  • Unshrouded
  • Number Of PCB Rows
  • 1
  • Lead Pitch
  • 2mm
  • Contact Length - Mating
  • 0.165 4.20mm
  • PCB Contact Pattern
  • RECTANGULAR

Download datasheets and manufacturer documentation for Harwin M22-5330505.

Datasheets:

M22-5330505 Overview


The packaging contains Header, Cuttable.There is a Surface Mount, Right Angle mounting type for the device.This product is packaged in a case marked Bulk.Product number M22 belongs to the M22 Series.Further, there are features such as ROHS COMPLIANT, to name only a few.Packaging with SIL contains a device.There is a Surface Mount mount on the part.This device operates at a temperature of -40°C~105°C.

M22-5330505 Features


M22 series


M22-5330505 Applications


There are a lot of Harwin Inc.
M22-5330505 Rectangular Connectors applications.
