ST LM193D
ST LM193D

ST LM193D

Manufacturer No:

LM193D

Manufacturer:

ST

Package:

SOIC

Description:

1.3 ?s ?s Linear Comparators 106.02dB dB 1992 1mA ?A 5mV mV Surface Mount

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

LM193D information

ST LM193D technical specifications, attributes, parameters and parts with similar specifications to ST LM193D.

  • Type
  • Parameter
  • Mount
  • Surface Mount
  • Package / Case
  • SOIC
  • Number of Pins
  • 8
  • Published
  • 1992
  • JESD-609 Code
  • e4
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 8
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Nickel/Palladium/Gold (Ni/Pd/Au)
  • Max Operating Temperature
  • 125°C
  • Min Operating Temperature
  • -55°C
  • Subcategory
  • Comparator
  • Technology
  • BIPOLAR
  • Terminal Position
  • DUAL
  • Terminal Form
  • GULL WING
  • Peak Reflow Temperature (Cel)
  • 260
  • Number of Functions
  • 2
  • Supply Voltage
  • 5V
  • Time@Peak Reflow Temperature-Max (s)
  • 30
  • Pin Count
  • 8
  • Output Type
  • OPEN-COLLECTOR
  • Power Supplies
  • 5V
  • Temperature Grade
  • MILITARY
  • Max Supply Voltage
  • 36V
  • Min Supply Voltage
  • 2V
  • Nominal Supply Current
  • 1mA
  • Max Supply Current
  • 1mA
  • Response Time
  • 1.3 ?s
  • Amplifier Type
  • COMPARATOR
  • Current - Input Bias
  • 250nA
  • Input Offset Voltage (Vos)
  • 5mV
  • Voltage Gain
  • 106.02dB
  • Average Bias Current-Max (IIB)
  • 0.4?A
  • Max Dual Supply Voltage
  • 18V
  • Min Dual Supply Voltage
  • 1V
  • Length
  • 4.9mm
  • Height Seated (Max)
  • 1.75mm
  • Width
  • 3.9mm
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for ST LM193D.

Datasheets:

LM193D Description


These gadgets are made up of two separate voltage comparators that can work independently from one power source across a wide range of voltages. As long as the difference between the two supplies is 2 V to 36 V and VCC is at least 1.5 V more positive than the input common-mode voltage, operation from dual supplies is also feasible. The supplied voltage has no effect on the current drain. To create wired-AND relationships, the outputs can be coupled to additional open-collector outputs.

The LM193 is designed to operate between 55°C and 125°C. The operating temperature range of the LM293 and LM293A is 25 °C to 85 °C. The operating temperature range of the LM393 and LM393A is 0°C to 70°C. The LM2903 is designed to operate between 40°C and 125°C.



LM193D Features


  • Low Supply-Current Drain Independent of Supply Voltage . . . 0.4 mA Typ Per Comparator

  • Low Input Bias Current . . . 25 nA Typ

  • Low Input Offset Current . . . 3 nA Typ (LM193)

  • Low Input Offset Voltage . . . 2 mV Typ

  • Common-Mode Input Voltage Range Includes Ground

  • Differential Input Voltage Range Equal to Maximum-Rated Supply Voltage . . . ±36 V

  • Low Output Saturation Voltage

  • Output Compatible With TTL, MOS, and CMOS



LM193D Applications


  • Power Management

  • Consumer Electronics

  • Portable Devices

  • Industrial
