ONSEMI LC75814VS-TLM-E

Manufacturer No:

LC75814VS-TLM-E

Manufacturer:

ONSEMI

Package:

30-LSSOP (0.220, 5.60mm Width)

Description:

Active DUAL Display Drivers ICs Tape & Reel (TR) Tin/Bismuth (Sn/Bi) 64

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

LC75814VS-TLM-E information

ONSEMI LC75814VS-TLM-E technical specifications, attributes, parameters and parts with similar specifications to ONSEMI LC75814VS-TLM-E.

Type
Parameter

Lifecycle Status
ACTIVE (Last Updated: 2 days ago)

Factory Lead Time
13 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
30-LSSOP (0.220, 5.60mm Width)

Number of Pins
30

Operating Temperature
-40°C~85°C

Packaging
Tape & Reel (TR)

Published
2001

JESD-609 Code
e6

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
4 (72 Hours)

Number of Terminations
30

Terminal Finish
Tin/Bismuth (Sn/Bi)

Subcategory
Other Interface ICs

Max Power Dissipation
100mW

Technology
CMOS

Voltage - Supply
2.7V~6V

Terminal Position
DUAL

Terminal Form
GULL WING

Terminal Pitch
0.635mm

Pin Count
30

Operating Supply Voltage
6V

Configuration
64 Segment

Interface
Serial

Operating Supply Current
230?A

Supply Current-Max
0.46mA

Display Type
LCD

Max Frequency
60kHz

Number of Segments
64

Number of Backplanes
4-BP

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for ONSEMI LC75814VS-TLM-E.

Datasheets:

onsemiconductor-lc75814vtlme-datasheets-8430.pdf

LC75814VS-TLM-E Overview

Similar to Tape & Reel (TR), the package has been designed in a similar manner.Version 30-LSSOP (0.220, 5.60mm Width) includes it.Its display type is LCD.The board mounts this electronic component using Surface Mount.Its operating temperature is -40°C~85°C.If you use a 2.7V~6VV power source, it should work.The 30 termination is used to terminate transmission lines with impedance-matched devices.A 30 pin makes up the entire device.With 30 pins, it is designed.A Surface Mount axis is used to mount this electronic component on the board in order to get the best fit.For 230?A to function properly, it requires current supply.64 segments refer to the segment of any of the Seller Group's equipment solutions business known as "Electronics".In addition, Other Interface ICs can include it.In order to achieve a high efficiency level, it is essential that the supply voltage is kept at 6V.The power supply used for this machine is the 3/5V power supply.A 4-BP backplane is an electronic circuit board.As far as frequency is concerned, it operates at 60kHz H60kHz.
