ST ISO8200BQ

Manufacturer No:

ISO8200BQ

Manufacturer:

Package:

TFQFPN-32

Description:

Description: Galvanic isolated octal high-side smart power solid state-relay

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISO8200BQ information

ST ISO8200BQ technical specifications, attributes, parameters and parts with similar specifications to ST ISO8200BQ.

Type
Parameter

RoHS Status
RoHS Compliant

Part Life Cycle Code
Active

Ihs Manufacturer
STMICROELECTRONICS

Package Description
TFQFPN-32

Reach Compliance Code
compliant

ECCN Code
EAR99

HTS Code
8542.39.00.01

Factory Lead Time
18 Weeks

Samacsys Manufacturer
STMicroelectronics

Built-in Protections
TRANSIENT; OVER CURRENT; OVER VOLTAGE; THERMAL; UNDER VOLTAGE

Driver Number of Bits
8

Input Characteristics
STANDARD

Interface IC Type
BUFFER OR INVERTER BASED PERIPHERAL DRIVER

JESD-30 Code
S-PQCC-N32

Length
11 mm

Number of Functions
1

Number of Terminals
32

Operating Temperature-Max
125 °C

Operating Temperature-Min
-40 °C

Output Current Flow Direction
SOURCE

Output Current-Max
1.3 A

Output Peak Current Limit-Nom
1.3 A

Package Body Material
PLASTIC/EPOXY

Package Code
HQCCN

Package Shape
RECTANGULAR

Package Style
CHIP CARRIER, HEAT SINK/SLUG

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Seated Height-Max
1.05 mm

Supply Current-Max
6 mA

Supply Voltage-Max
5.5 V

Supply Voltage-Min
2.75 V

Supply Voltage-Nom
3.3 V

Supply Voltage1-Max
36 V

Supply Voltage1-Min
10.5 V

Supply Voltage1-Nom
24 V

Surface Mount
YES

Temperature Grade
AUTOMOTIVE

Terminal Form
NO LEAD

Terminal Position
QUAD

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Turn-off Time
40 µs

Turn-on Time
22 µs

Width
9 mm

Download datasheets and manufacturer documentation for ST ISO8200BQ.

Datasheets:

en.DM00152250.pdf

ISO8200BQ Overview

It's packaged in the way of a Tray.It's included in the 32-TQFN Exposed Pad package.The mounting type of the LED driver is Surface Mount.It owns Relay, Solenoid Driver switch type.The temperature should be set to -40°C~125°C TJ to ensure reliable functioning.By default, it is set to output 8.The lighting driver has Auto Restart, Status Flag features.It belongs to the ISO82 family.The output current is set to 700mA in this case.

ISO8200BQ Features

ISO8200BQ Applications

There are a lot of STMicroelectronics
ISO8200BQ Power Switches ICs applications.

Smartphone and PDA
Portable GPS Device
Set-top-box
USB Power Distribution
Notebook PC
Telecom and Network Systems
PC Card Hot Swap
Storage Drives
Portable/Handheld Devices
Wireless/Networking Cards
