Manufacturer No:

SPWF01SA.21

Manufacturer:

ST

Package:

Module

Description:

2.4GHz WiFi -40°C~85°C UART Tray Integrated, Chip 65Mbps 18.3dBm 802.11b/g/n -96dBm Module

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

SPWF01SA.21 information

ST SPWF01SA.21 technical specifications, attributes, parameters and parts with similar specifications to ST SPWF01SA.21.

  • Type
  • Parameter
  • Contact Plating
  • Gold
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • Module
  • Number of Pins
  • 30
  • Operating Temperature
  • -40°C~85°C
  • Packaging
  • Tray
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • 3 (168 Hours)
  • Number of Terminations
  • 25
  • ECCN Code
  • 5A992.C
  • Terminal Position
  • UNSPECIFIED
  • Number of Functions
  • 1
  • Supply Voltage
  • 3.3V
  • Frequency
  • 2.4GHz
  • Base Part Number
  • SPWF01
  • JESD-30 Code
  • R-XXMA-N25
  • Operating Supply Voltage
  • 3.3V
  • Number of Channels
  • 1
  • Memory Size
  • 512kB Flash 64kB RAM
  • Data Rate
  • 65Mbps
  • Protocol
  • 802.11b/g/n
  • Telecom IC Type
  • TELECOM CIRCUIT
  • Power - Output
  • 18.3dBm
  • Antenna Type
  • Integrated, Chip
  • Sensitivity
  • -96dBm
  • Serial Interfaces
  • UART
  • Current - Receiving
  • 105mA
  • Current - Transmitting
  • 210mA~344mA
  • Modulation
  • DSSS, OFDM
  • Sensitivity (dBm)
  • -96 dBm
  • Length
  • 26.924mm
  • Height Seated (Max)
  • 2.45mm
  • Radiation Hardening
  • No
  • RoHS Status
  • ROHS3 Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for ST SPWF01SA.21.

Datasheets:

SPWF01SA.21 Overview


It adopts the way of Surface Mount for RF Transceiver' mounting.This RF Transceiver module utilizes the Tray package for optimized performance.There are 25 terminations in this RF Transceiver module.When operating, Transceiver's operating temperature should be kept at -40°C~85°C.This high power Transceiver belongs to the SPWF01 family.30 pins are used for high power RF Transceiver operation.The RF Transceiver Module operates at a frequency of 2.4GHz.Surface Mount mounted, this Transceiver is widely used in many applications.

SPWF01SA.21 Features


Surface Mount
Tray package
25 terminations
SPWF01
30 pins


SPWF01SA.21 Applications


There are a lot of STMicroelectronics
SPWF01SA.21 RF Transceiver Modules applications.


  • Low-power IoT applications
  • LoT applications
  • Power Amplifier (PA)
  • Low Noise Amplifier (LNA)
  • Transmit
  • Receive
  • Switch
  • Power management
  • Internet of Things (IoT)
  • Secure Payment

User Guide
