Renesas ISL84780IR-T

Manufacturer No:

ISL84780IR-T

Manufacturer:

Renesas

Package:

QFN

Description:

QUAD Analog Switches BREAK-BEFORE-MAKE 16 Pins 3V QFN

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL84780IR-T information

Renesas ISL84780IR-T technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL84780IR-T.

Type
Parameter

Mount
Surface Mount

Package / Case
QFN

Number of Pins
16

Published
2001

JESD-609 Code
e0

Part Status
Discontinued

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
16

Resistance
600mOhm

Terminal Finish
Tin/Lead (Sn/Pb)

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Subcategory
Multiplexer or Switches

Technology
CMOS

Terminal Position
QUAD

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
240

Number of Functions
4

Supply Voltage
3V

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Pin Count
16

Qualification Status
Not Qualified

Supply Voltage-Max (Vsup)
3.6V

Temperature Grade
INDUSTRIAL

Supply Voltage-Min (Vsup)
1.6V

Number of Channels
1

Number of Circuits
4

Operating Supply Current
50nA

Throw Configuration
SPDT

Supply Type
Single

Supply Current-Max (Isup)
0.0015mA

Off-state Isolation-Nom
68 dB

On-state Resistance Match-Nom
0.13Ohm

Switching
BREAK-BEFORE-MAKE

Switch-on Time-Max
20ns

Signal Current-Max
0.3A

Length
3mm

Height Seated (Max)
1mm

Width
3mm

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for Renesas ISL84780IR-T.

Datasheets:

intersil-isl84780irt-datasheets-4407.pdf

ISL84780IR-T Overview

The electrical component comes in QFN packaging, which makes it convenient to ship overseas. In total, 16 terminations have occurred. A electrical component with 1 channels is capable of high-quality output. When the electronic component is given a voltage of 3V, it should be turned on and run. As part of the design of the 16 series, this electronic part has been incorporated into the system. Circuits number 4 make up this analogue multiplexer. A 600mOhm internal resistance characterizes this multiplexer. The datasheets for the 16 pins explain the functions. The analog multiplexer shown here is a typical Multiplexer or Switches. A analog switch ic that has a cost-effective Single supply type. The analogue multiplexer could operate on 50nA current. A temperature above 85°C is not suitable for operation of the analogue multiplexer. This analog switch ic needs a voltage of 1.6V as its minimum supply voltage.

ISL84780IR-T Features

1 Channels
50nA Supply Current

ISL84780IR-T Applications

There are a lot of Intersil (Renesas Electronics America)
ISL84780IR-T Analog Switches & Multiplexers ICs applications.

Audio and video switching
Automatic test equipment
Precision data acquisition
Battery-powered systems
Sample-and-hold systems
Communication systems
Data Acquisition Systems
Relay Replacement
Battery Powered Systems
Existing multiplexer applications (both fault-protected and nonfault-protected)
