Renesas ISL78302ARNBZ

Manufacturer No:

ISL78302ARNBZ

Manufacturer:

Renesas

Package:

DFN

Description:

Fixed 0.5mm PMIC 10 DFN

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL78302ARNBZ information

Renesas ISL78302ARNBZ technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL78302ARNBZ.

Type
Parameter

Factory Lead Time
9 Weeks

Mount
Surface Mount

Package / Case
DFN

Number of Pins
10

Published
2002

JESD-609 Code
e3

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
10

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
105°C

Min Operating Temperature
-40°C

Subcategory
Other Regulators

Technology
CMOS

Terminal Position
DUAL

Terminal Pitch
0.5mm

Pin Count
10

Number of Outputs
1

Output Type
Fixed

Polarity
Positive

Current - Output
300mA

Quiescent Current
47μA

Accuracy
0.8 %

Output Voltage 1
3.3V

Number of Regulators
2

Min Input Voltage
2.3V

Max Input Voltage
6.5V

Dropout Voltage
300mV

Dropout Voltage1-Nom
0.3V

Power Supply Rejection Ratio (PSRR)
64dB

Min Current Limit
320mA

Output Voltage 2
1.5V

Height
900μm

Length
3mm

Width
3mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Renesas ISL78302ARNBZ.

Datasheets:

intersil-isl78302arnbz-datasheets-0691.pdf

ISL78302ARNBZ Overview

A DFN case is used for packaging. As you can see, the IC chip has 10 terminations. Regulator IC chip's output type is Fixed. The electronic part implements 2 regulators in total. As far as its current output is concerned, it stands at 300mA. This chip has a total of 10 pins, which are arranged in a rectangular shape. It has 1 outputs to ensure that the performance of this regulator is prompt and sufficient. The dropout voltage of the regulator IC is 10 volts. 10 pins are on the chip. The component shown here is a typical Other Regulators component. It operates in the 47μA Quiescent Current state. The temperature should be below 105°C when you use the IC voltage regulator. There is no operating temperature below -40°C for the chip. In general, this IC voltage regulator is able to output 1.5V volts on a system basis.

ISL78302ARNBZ Features

300mV dropout voltage
Other Regulators subtageroy
The maximum operating temperature of -40°C

ISL78302ARNBZ Applications

There are a lot of Intersil (Renesas Electronics America)
ISL78302ARNBZ Linear Voltage Regulators applications.

Communication device
Personal communication device
Portable telephone
Electronic notebook
Camera
Video equipment
CPU power supply
Switching regulator
Multiple-power supply system
Digital audio player
